Description
Nov Varco Top Drive IBOP
Ibop Model O.D. I.D. L Thread Api
InMmInMmInMm
Hydraulic187 Ibop 7-23/64 187 3-1/16 78 22-1/2 572 6-5/8 Reg Box-6-5/8 Reg Box
Manual 187 Ibop 7-23/64 187 3-1/16 78 22-19/32 523 6-5/8 Reg Box-6-5/8 Reg Pin
Canrig Top Drive Ibop
Hydraulic195.5 Ibop 7-11/16 195.5 2-13/16 71.4 29-7/16 748.5 6-5/8 Reg Box-Nc50 Pin
Jh Jinghong Dq Top Drive Ibop
Hydraulic197 Ibop 7-3/4 197 2-15/16 75 20-1/2 521 6-5/8 Reg Box-6-5/8 Reg Pin
Hydraulic Manual Intergrated 197 Ibop 7-3/4 197 2-15/16 75 37-51/64 960 6-5/8 Reg Box-6-5/8 Reg Pin
Bpm Dq Top Drive Ibop
Dq70 Hydraulic197 Ibop 7-3/4 197 3 76.2 23 584 6-5/8 Reg Box-6-5/8 Reg Pin
Dq70 Manual 197 Ibop 7-3/4 197 3 76.2 20-5/32 512 6-5/8 Reg Box-6-5/8 Reg Pin
Dq90hydraulic216 Ibop 8-1/2 216 3-1/16 78 20-3/4 603 7-5/8 Reg Box-7-5/8 Reg Pin
Dq90manual 216 Ibop 8-1/2 216 3-1/16 78 20-63/64 533 7-5/8 Reg Box-7-5/8 Reg Pin
Tpec Dq Top Drive Ibop
Dq70hydraulic197 Ibop 7-3/4 197 3 76.2 22-1/2 572 6-5/8 Reg Box-6-5/8 Reg Box
Dq70manual 197 Ibop 7-3/4 197 3 76.2 20-3/5 523 6-5/8 Reg Pin-6-5/8 Reg Box
Iii Type Hydraulic197 Ibop 7-3/4 197 3 76.2 22-1/2 572 6-5/8 Reg Box-6-5/8 Reg Box
Iiitype Manual 197 Ibop 7-3/4 197 3 76.2 21-3/32 536 6-5/8 Reg Pin-6-5/8 Reg Box
Cross Over Sub 7-23/64 187 2-1/4 57.2 17-1/2 445 6-5/8 Reg Pin-Nc38 Pin
Cross Over Sub 7-23/64 187 2-1/4 57.2 17-1/2 445 6-5/8 Reg Pin Lh-Nc38 Pin Lh
Cross Over Sub 7-23/64 187 2-13/16 71.4 18 458 6-5/8 Reg Pin-Nc50 Pin
Cross Over Sub 7-3/4 197 2-1/4 57.2 18 458 6-5/8 Reg Pin-Nc38 Pin
Cross Over Sub 7-3/4 197 2-13/16 71.4 18-1/2 470 6-5/8 Reg Pin-Nc50 Pin
Cross Over Sub 7-3/4 197 2-13/16 71.4 18 458 6-5/8 Reg Pin Lh-Nc38 Pin Lh
Hh Dq Top Drive Ibop
Dq70hydraulic190 Ibop 7-31/64 190 2-15/16 75 21-1/2 547 6-5/8 Reg Box-6-5/8 Reg Pin
Dq70hydraulic200 Ibop 7-7/6 200 2-15/16 75 21-1/2 547 6-5/8 Reg Box-6-5/8 Reg Pin
Dq70manual 190 Ibop 7-31/64 190 2-15/16 75 21-1/2 547 6-5/8 Reg Box-6-5/8 Reg Pin
Dq70manual 200 Ibop 7-7/6 200 2-15/16 75 21-1/2 547 6-5/8 Reg Box-6-5/8 Reg Pin
Dq90hydraulic 215 Ibop 8-1/2 215 3-1/16 78 32 815 7-5/8 Reg Box-6-5/8 Reg Pin
Bomco Dq Top Drive Ibop
Dq70manual 197 Ibop 7-3/4 197 3 76.2 20-63/64 532 6-5/8 Reg Box-Nc50 Pin
Hbs Top Drive Ibop
Hydraulicφ228 9 228 3.5 88.9 23.13 587 Api 7-5/8 Reg Rh Pin-Api 7-5/8 Reg Rh Box
Manual Φ228 9 228 3.5 88.9 15.88 533 Api 7-5/8 Reg Rh Pin-Api 7-5/8 Reg Rh Box
30177460 Cover, Blower
122954-2 Spacer, Upper, Encoder, Tds9
122955 Spring, Torsion, Tds9
122953-500 Arm, Support, Encoder, Tds9
122956 Spacer, Encoder, Tds9
122943-501 Mount, Plate, Encoder, Tds9
109557 (Mt)Washer, 300ss
110010 (Mt)Cover, Access, Weldment
122249 Bracket, Heat-Exchanger
112809-04 Cap, Plastic Sae-04
112809-06 Cap, Plastic Threaded Shipping
112809-08 Cap, Plastic Sae-08
30172726-1 Pin, Secondary Retention, .81″Dia.Ph-100
30172825 Pivot Pin Double Retention
129991-01 Gland, Eexd/Eexe, M16x1.5
86874-500 Assy, Grounding Ear
82570+30 Adhesive, Rubber, Tds, C/W Msds Sheet
129829-1 Sheet Neoprene
129783-8 Plate, Bracket
129783-6 Plate, Bracket
129783-4 Plate, Bracket
118866 Bar, Assy, Earthing
94872-3 Lug, Copper Connector
129783-502 Bracket, Connector
98692 Drain, Breather, Soh=0, R/B 30158431-2
88617-P12m20 Reducer, 3/4mnpt/M20f
129991-07 Gland, Eexd/Eexe, M50x1.5 Soh=0 Use – See
110109-3 Plate, Blower, Duct
110109-4 Plate, Blower, Duct
122943-500 Mount, Plate, Encoder, Tds9
M854000259 Mfld Asy, Prefill Vlve**(Replaces 111712)
50016-32-C8d Screw, Cap-Hex Hd (Unc)
50016-24-C8d Screw, Cap Hex Hd Drilled
82674-Ce Accumulator, Piston 4.0 Bore (See Text)
50804-Ns
109557 (Mt)Washer, 300ss
80569 Nut, Hex, Jam, 2.0-12 Un, Tds-11, Varco 80569
30157306 Pin, Lynch, Tds-11, Varco 30157306
111711 Guide Disc, 0.407 X 0.684, Steel, Varco 111711
91923 Seal, Tds-11, Varco 91923
56556-16-12-S Fitting, Reducer, Boss O-Ring, Varco 56556-16-12-S
56501-24-16-S Fitting, Adapter, Straight, Steel, Varco 56501-24-16-S
122627-46 Remote-I/O, Digital, 24in/8out
122627-45 Remote-I/O, 4pt, Analog
122627-58 Base, Digital, Siemens S7
96290+30 Tp Pcb, +5v Regulator Bd
Pr1003a-19 Tachometer, 250 Rpm, Varco (Replaces 96218-3)
30087708-67 Sw, Pb Mushroom Hd Lr/Red
96219-11 Meter, Torque, Ft-Lb, 60000, Tds11 (Ght103a-000480)
122627-57 Base, Analog, Siemens S7,
0000-6999-19 Plc, Conn, Profibus (Replaces 122627-34)
116551 Throttle, Vdc, Tds9s
30087708-40 Indicating Light, 24v Dc Amber
81736-2 Potentiometer, 2w, 10k
30087708-46 Dc Operator, Pot
30087708-02 Screw, Cap-Sck Hd
30087708-44 Lamp Min. Bayonet 24v
107865-16 Pdm Hpu Strainer, Sump 1.0
71613 Breather, Reservoir
110703 Actuator Assy, Counter Balance
110704 Actuator, Assy, Counter Balance
51208-14 Pin, Dowel
117939 Gear, Helical, Pinion
109554 Hub, Brake
117830 Gear, Pinion
30151875-504 Assy, Hyd Drive, Shotpin, 40 X 25 Tds-11s
30158574 Gear, Bull, Helical (Replaces 117938)
30158573 Gear, Compound, Helical (Repalces 117937)
110040-1 Sleeve, Mainshaft, Tds11
109591 (Mt)Sleeve, Flanged, 7.87id, 300ss
91829-1 (Mt)Sleeve, Stem, Std.Bore, Tds
109561 (Mt)Impeller, Blower (P)
110011 (Mt)Gasket, Cover, Access
110014 Gasket, Blower, 7.6×12.5
110015 Gasket, Blower, 7.6×8.5
110016 Gasket, Blower, 7.6×11.6
110017+30 Gasket, Blower, 7.5×7.6
110112 (Mt)Gasket, Blower, Scroll
110110 Gasket, Duct, Blower
51300-425-B 0-Ring, “S” Tube, Tds
77039 Seal, Lip 8.25×9.5x.62
91250-1 (Mt)Oil Seal(Viton), Std.Bore, Tds
98291+30 Seal, Polypak, 3.875, Std.Bore, Tds
110039 (Mt)Pin, Dowel, 1.25diax3.8, Ms27
118378 Retainer, Landing, Collar
118377 Collar, Landing (2 Halves =Qty 1)
110008 (Mt)O-Ring, .275×50.5
51300-223-F O-Ring
51300-258-B O-Ring
51300-277-B O-Ring
51300-279-B O-Ring
51300-385-F O-Ring
51300-387-F O-Ring
51300-273-B O-Ring
51300-381-B O-Ring
30119319 Ring, Glyd, 11.0dia-Rod
30119143 Ring, Glyd, 11.5 Dia-Rod(S48130-340a-29)
119547 Seal, Wiper, 11.0dia-Rod
110562-1 Tds9s Accum, Hydro-Pneu 6″
110563-1 Tds9s Accum, Hydro-Pneu 4″
110564-1 Tds9s Accum, Hydro-Pneu 2″
M854000259 Mfld Asy, Prefill Vlve**(Replaces 111712)
56541-16-S Flange Clamp, Sae Hydraulic; Code 61; Sp
56541-12 Kit, Split Flange
76442 Guide, Arm
76443 Compression Spring 1.95
120557 Actuator, Double-Rod, .25diax2.0
119416 Actuator, Hyd, 3.25diax10.3st
72219 Seal, Piston
72220 Seal Rod
72221 Wiper, Rod
30124898 Stabilizer, Front(Ph100)
30178859 Retainer, Hinge Pin, Ph 75 And Ph100
30158690 Liner, Stabilizer
79179 Spring, Compression, 1.0×2.0×3.0
16532+50 Key, .50 Square X 2.8, 1018 Stl
30157308 Spring, Compression Ph-75
118844-16-08 Bushing, Sleeve, 1.00×0.50, Fiberglide
118844-16-12 Bushing, Sleeve, 1.00×0.75, Fiberglide
118844-22-22 Bushing. Sleeve, 1.38×1.38, Fiberglide
79824 Cam-Follower, 1.0diax.62stud
119387 Pin, 2.0diax7.5, Ms15
110042 Shell, Actuator (Ph50)
98898+30 Crank, Assy, External
30119592 Actuator, Assy
30179918 30179918
30152845 30152845
53600-40 53600-40
105643-12 105643-12
111710+30 111710+30
56551-16-12s 56551-16-12s
121131 Main Shaft
50186-10-01 Screw, Cap-Button Hd
82838 Chain, .5
50824-R-C Washer, Flat
50524-C Nut, Hex-Sltd, (Unc-2b)
50308-C Nut, Hex-Jam
109411 Exchanger, Heat
97998+30 Ring, Retaining, 8.000bore
97997+30 Ring, Retaining, Internal
88991 Plug, Reducing, Flow
51603-4-S Pin, Roll
50105-4-S Screw, Cap-Soc Hd (Unc
115340 Shoe, Split
M614005119 Kit, Impro Air Purge, Std Bore
75981 Gasket, Retainer, Seal
81628+30 Bushing, Sleeve, 1.0×1.25, 1.125
114895 Collar, Assy, Landing
114895 Collar, Assy, Landing
80389+30 Pin, Clevis, 1.26diax4.62
2170-54 Kit, Insert – Sdxl/Sdl
2170-54 Kit, Insert – Sdxl/Sdl
6907325s Gasket, Ring Joint (Replaces Bx155)
50665 Rg Gskt, Bx-164, Cad Pltd (Replaces Bx-164)
2630 Circular Button, 6-3/4 – 11-1/4
108894-L25 Seal, Lip, Piston (Same As16701-3, 87018-2
98899+30 Crank, Arm
99168+30 Spacer, Sleeve, .88odx.636idx.250thk
105599 Ids Seal V-Ring
110083 Spring, Compression
110548 Tds9s Glyd-Ring, Rotary Ph
114833 Seal, Lip, 4.0
108119-16b Pdm Hpu Sight Gauge
110548 Tds9s Glyd-Ring, Rotary Ph
112848 Lock, Tool, Joint (Replaces 111924)
112621 Pin, Shot, Tds9s
30112625 Sleeve, Shot-Pin, Tds9s
126800-01-20 Pigtail, Assy, 42cond Eex
126801-01-20 Assy, Pigtail, 18-Cond, Eex
128694-6-031 Flow Control
51300-220-B O-Ring Crank Assy, Tds
30175266-18 Plate, Wear
30175266-6 Plate, Pressure
117513-Pf-Wht Connector, Qd, Pin W/Inline Flange
117513-Sl-Wht Connector, Qd, Power, 444, Skt/Inline, White
109567-T Tds9s Plate, Thrust
30124898 Stabilizer, Front(Ph100)
118844-16-24 Bushing, Sleeve, 1.00×1.50, Fiberglide
30119597 Sleeve, Spring, 2.1×3.25 Dia
109567-S Tds9s Seal, Body
50016-18-C5d Screw, Cap-Hex Hd Drilled
51716-24-C Bolt, Shoulder-Soc Hd
50924-C Washer, Lock-Regular
50812-N-C Washer, Flat
50320-C Nut, Hex-Jam
87196-10-S Plug, O-Ring Srt Thd Rec Hex
50005-20-C5d Screw, Cap-Hex Hd (Unc)
50314-C Hex Jam Nut, 7/8
50310-C Nut, Hex-Jam
51016-C Washer, Lock-Heavy
50516-C Nut, Hex-Sltd (Uncb-2b)
50008-13-C5d Screw, Cap-Hex Hd Drilled
50816-N-C Washer, Flat
50070-025f06 Screw, Cap-Hex, Metric
50006-10-C5d Screw, Cap-Hex Hd Drilled
51007-C Washer, Lock
50806-N-C Washer, Flat
110147-1 Shim, Reservoir, .002 Tds9s
50016-28-C5d Screw, Cap-Hex Hd Drilled
30158574 Gear, Bull, Helical (Replaces 117938)
30158573 Gear, Compound, Helical (Repalces 117937)
114869-Sl-Wht Connector, Power, Qd, Socket/Inline, White
51300-349-B O-Ring
50114-22-Cd Screw, Cap Soc-Hd
50012-16-C5d Screw, Cap-Hex Hd Drilled
55016-22-C5d Screw (1″Unf-12-2a) Drilled Head
50008-10-C5d Screw, Cap-Hex Hd Drilled
50016-48-C5d Screw, Cap-Hex Hd Drilled, Tds
50006-5-C5d Screw, Cap-Hex Hd Drilled
50003-6-C5d Screw, Cap-Hex Hd 10-24
50008-14-C5d Screw, Cap-Hex Hd Drilled
50010-16-C5d Screw, Cap-Hex Hd Drilled
50005-10-C5d Screw, Cap-Hex Hd Drilled
50008-7-C5d Screw, Cap-Hex Hd Drilled
50008-20-C5d Screw, Cap-Hex Hd Drilled
50006-8-C5d Screw, Cap-Hex Hd Drilled
50004-12-C5d Screw, Cap-Hex Hd (Unc-2a)
50004-10-C5d Screw, Cap-Hex Hd Drilled
50010-14-C5d Screw, Cap-Hex Hd Drilled
50010-12-C5d Screw, Cap-Hex Hd Drilled
50810-R-C Washer, Flat
50910-C Washer, Lock-Regular
50914-C Washer, Lock Regular
50914-C Washer, Lock Regular
50916-C Washer, Lock-Regular
86871-20 Tds Nylon Washer 20mm
50804-R-C Washer, Flat
50904-C Washer, Lock-Regular 1/4″
51810-C Nut, Hex-Self Locking
30125972 U-Bolt, Linktilt, 500
30177570 Bracket, Link Tilt Ph100
50908-C Washer, Lock
107052 Washer, Lock, Tab, .56 Dia
50514-C Nut, Hex-Sltd, (Unc-2b)
51435-20 Cotter Pin
51805-C Nut, Hex-Self Locking
30176544 Assy, Hyd Cyl, Link-Tilt, Ph-100
30171518-1 Seal-Kit, Hyd.Cyl.
56529-8-8-S Conn, O-Ring Boss/37
56529-8-6-S Conn, O-Ring Boss/37
56529-6-6-C Conn, O-Rinb Boss/37
56529-6-6-S Conn, O-Ring Boss/37
30182002-20 Upper Ring
30182002-13 Spring
56555-6-S Tee, 37/37/O-Ring Boss
110056 Seal, Rod, 1.5bore
30173958 Shot Pin, Ph-100
1 121277 BODY,MAIN-500 TON
2 109518 COVER,MAIN BODY
3 121131 MAIN SHAFT W/LANDING COLLAR
4 30173277 ROTATING LINK ADAPTER ASSY-500 TON
5 109531 BONNET
6 117603-1 PUMP ASSEMBLY,LUBE (ALUM)
7 110068-2 ASSEMBLY,RESERVOIR-HYDRAULIC OIL
8 110013 BRACKET,RESERVOIR
9 30122104 HEAT EXCHANGER,OIL
10 122249 BRACKET,HEAT EXCHANGER
11 30151875-500 ASSEMBLY,HYD DRIVE/SHOT PIN,STAINLESS STEEL
12 30123290 ASSEMBLY,WASH PIPE
13 30158574 GEAR,BULL,HELICAL
14 30158573 GEAR,COMPOUND,HERICAL
15 30123290-1000 ASSEMBLY,WASH PIPE
16 110040-1 SLEEVE,MAIN SHAFT
17 109591 SLEEVE,WEAR
18 91829-1 SLEEVE STEM
19 117987 BEARING,SPHERICAL ROLLER-COMPOUND LOWER
20 109519 BEARING,TAPER
21 1205656 BEARING,THRUST-TAPPER ROLLER
22 109521 BEARING,CYLINDER ROLLER-MAIN LOWER
23 109522 BEARING,CYLINDRICAL ROLLER-COMPOUND UPPER
24 118668 RETAINER,BEARING-UPPER STEM
25 109593 RETRAINER,BEARING
26 109594 COVER,BEARING
27 109594-1 COVER,BEARING
28 122248 FASTENING BLOCK
29 109528 BRAKE,CALIPER DISC
30 109555 ROTOR,BRAKE
31 109553 ADAPTER PLATE,BRAKE
32 116661-1 MOUNTING PLATE,MOTOR
33 30126111 MOUNTING PLATE,BLOWER MOTOR
34
35 DELETED
36 115879 MOUNT,CABLE
37 109561 IMPELLER,BLOWER
38
39
40 113246 BRACKET,PRE-FILL VALVE
41 118217-40R60 MOTOR ASSY,DRILL AC-575 VAC(R.H.)(400 HP)
42 118217-40L60 MOTOR ASSY,DRILL AC-575 VAC(R.H.)(400 HP)
43
44 109563-1 DUCT
45 109563-2 DUCT
46 109592-1 COVER,BLOWER SCOLL BRAKE
47 109592-2 COVER,BLOWER SCOLL BRAKE
48 110001 COVER,BLOWER
49 110002 COVER,BLOWER
50 110003 COVER,BLOWER
51 110004 COVER,BLOWER
52 110010 COVER,ACCESS
53 110011 GASKET,ACCESS COVER
54 110014 GASKET,BLOWER
55 110015 GASKET,BLOWER
56 110016 GASKET,BLOWER
57 110017 GASKET,BLOWER
58 110012 GASKET,BLOWER SCROLL
59 110110 GASKET,DUCT/BLOWER
60
61 110116 GASKET,DUCT/MOTOR
62
63
64 108216-12 BALL VALVE
65
66 88990-9 NOZZLE,SPRAY-FLAT PATTERN
67 88990-10 NOZZLE,SPRAY-FLAT PATTERN
68 109566 TUBE,UPPER BEARING LUBE
69 109523 ADAPTER
70 119977 LABEL,WARNING
71
72 109586-1 SHIM,BEARING RETAINER
73 109586-2 SHIM,BEARING RETAINER
74 109586-3 SHIM,BEARING RETAINER
75 109586-4 SHIM,BEARING RETAINER
76 109586-5 SHIM,BEARING RETAINER
77 110147-1 SHIM,RESERVOIR MOUNTING (.002)
78 110147-2 SHIM,RESERVOIR MOUNTING (.005)
79 110147-3 SHIM,RESERVOIR MOUNTING (.010)
80 110147-4 SHIM,RESERVOIR MOUNTING (.031)
81 56531-2-S PLUG,O-RING BOSS(WITH O-RING)
82
83 56710-4-2-S REDUCER,PIPE-INT/EXT
84 141304 VALVE,RELIEF
85 118456 BEARING ISOLATOR
86 110078 FERRULE,SAFTY CABLE .032
87 110078-L36 CABLE,SAFTY- .032 * 36”
88 110078-L24 CABLE,SAFTY- .032 * 24” (NS)
89 110078-L18 CABLE,SAFTY- .032 * 18”
90
91 78736-14 CLAMP,SUPPORT 2.25+/-.0 (NS)
92
93
94 53002-12-S PLUG,PIPE SQUARE HEAD
95 122247-1 TUBE,HEAT EXCHANGER-1/2”
96 122247-2 TUBE,HEAT EXCHANGER-1/2”
97
98 DELETED
99 110172 TUBE ASSEMBLY,BRAKE
100 117116 TUBE ASSEMBLY,BRAKE,RIGHT
101 110173 TUBE ASSEMBLY,BRAKE (NS)
102 109538 RING,RETAINING
103 96648-1 RING,RETAINING
104 51300-425-B O’RING (RP)
105 77039 SEAL (RP)
106 91250-1 SEAL,OIL (RP)
107 98291 SEAL,POLYPAK
108 98290 LINER,UPPER STEM
109 30118959(老号：30154362） SHIELD,BEARING (RP)
110 109539 SPACER,RING
111 117116-501 TUBE ASSEMBLY,BRAKE,LEFT
112 110039 PIN,DOWEL
113 30171956 TUBE ASSEMBLY,BRAKE,BOTTOM
114 30171957 TUBE ASSEMBLY,BRAKE,TOP
115 105520 TAG,ASSY
116 53301-4-4-SS SCREW,DRIVE-TYPE U
117
118
119 118378 RETAINER,LANDING COLLAR
120 118377 COLLAR,LANDING (SET)
121 121272-1 TUBE ASSEMBLY,BREATHER
122 121272-2 TUBE ASSEMBLY,BREATHER
123 30172172 SCREW,CAP-HEAD HEX
124 51216-24 PIN,DOWEL
125 51401-8 PIN,COTTER
126 110008 O-RING,MAIN BODY/COVER (RP)
127 51300-016-B O-RING,OIL LUBE TUBE (RP)
128 51300-223-F O-RING,MAIN BODY/OIL GALLERY (RP)
129 51300-258-B O-RING,MAIN BODY/BEARING COVER (RP)
130 51300-277-B O-RING,COVER/BEARING RETAINER (RP)
131 51300-279-B O-RING,MAIN BODY/OIL PUMPADAPTER (RP)
132 51300-385-F O-RING,MAIN BODY/STEM (RP)
133 51300-387-F O-RING,MOTOR/COVER (RP)
134 53912 NIPPLE,CLOSE
135
136
137 53219-2 FITTING,GREASE – STRAIGHT EXTENDED .125-27 NPT
138 52212-B ELBOW,90′-COMMON (150LB)
139 94041-18 ORIFICE,1/16 NPT – .071
140 94042-12 ORIFICE,1/8 NPT – .047
141 110844-52 ORIFICE,1/4 NPT – .205
142 53000-2-C PLUG,EXT PIPE – COUNTERSUNK HEX
143 53000-4-C PLUG,EXT PIPE – COUNTERSUNK HEX
144 53000-6-C PLUG,EXT PIPE – COUNTERSUNK HEX
145 53000-8-C PLUG,EXT PIPE – COUNTERSUNK HEX
146 53000-12-C PLUG,EXT PIPE – COUNTERSUNK HEX
147 53000-48-C PLUG,EXT PIPE – COUNTERSUNK HEX
148 53002-32-C PLUG,PIPE – SQUARE HEAD
149 53003-16 PLUG,MAGNETIC
150 56531-4-S PLUG,O-RING BOSS (WITH O-RING)
151 56531-8-S PLUG,O-RING BOSS (WITH O-RING)
152 94821 PLUG,MODIFIED – 3-8 NPT
153 56529-10-8-S CONNECTOR,EXT PIPE/37′
154 56529-4-4-S CONNECTOR,O-RING BOSS/37′
155
156 56529-8-8-S CONNECTOR,O-RING BOSS/37′
157 56525-4-4-S TEE,SWIVEL INT 37’/37’/37′
158 56502-2-4-S ELBOW,45′ EXT PIPE /37′
159 DELETED
160
161 56506-6-4-S ELBOW,90′ EXT PIPE /37′
162 52824-12-B BUSHING,PIPE REDUCING-COMMON
163 56519-12-8-S ELBOW,O-RING BOSS/37′ (NS)
164 DELETED
165
166 50010-10-C5D SCREW,HEX HEAD CAP
167 50010-18-C5D SCREW,HEX HEAD CAP
168 50012-12-C5D SCREW,HEX HEAD CAP (NS)
169 50012-16-C5D SCREW,HEX HEAD CAP
170 50012-18-C5D SCREW,HEX HEAD CAP
171 50012-20-C5D SCREW,HEX HEAD CAP
172 50012-24-C5D SCREW,HEX HEAD CAP
173 50012-26-C5D SCREW,HEX HEAD CAP
174 50010-10-C5D SCREW,HEX HEAD CAP
175 50016-12-C5D SCREW,HEX HEAD CAP (NS)
176 50016-18-C5D SCREW,HEX HEAD CAP
177 50016-28-C5D SCREW,HEX HEAD CAP
178 50004-5-C5D SCREW,HEX HEAD CAP (NS)
179 50006-12-C5D SCREW,HEX HEAD CAP
180 50505-C NUT,HEX SLOTTED
181 512218-18 LOCKNUT,INTERNAL RETAINER
182 51217-18 LOCKWASHER,BEARING
183 109557 WASHER
184 50904-C WASHER,LOCK – REGULAR
185 50905-C WASHER,LOCK – REGULAR
186 50906-C WASHER,LOCK – REGULAR
187 50908-C WASHER,LOCK – REGULAR
188 50910-C WASHER,LOCK – REGULAR
189 50912-C WASHER,LOCK – REGULAR
190 50916-C WASHER,LOCK – REGULAR
191 53200-242 COMPOUND,LOCKING (BLUE)
192 Z6000.9 LOCKWIRE,.051
193 Z6001 LOCKWIRE,.047
194 50008-12-SD SCREW,CAP-HEX HD DRILLED
195 50908-S WASHER,LOCK-REGULAR
196 50004-12-C5D SCREW,HEX HEAD CAP (NS)
197 50004-6-C5D SCREW,HEX HEAD CAP
198 94269-2 CLAMP,SINGLE – 1/4” TUBE,PHM3i (NS)
199 50005-8-C5D SCREW,HEX HEAD CAP
200 50005-12-C5D SCREW,HEX HEAD CAP
201 50005-6-C5D SCREW,HEX HEAD CAP
202 50005-10-C5D SCREW,HEX HEAD CAP
203 Z6000.8 LOCKWIRE,.031
204 50006-10-C5D SCREW,HEX HEAD CAP
205 50008-8-C5D SCREW,HEX HEAD CAP
206
207 50008-10-C5D SCREW,HEX HEAD CAP
208 50008-11-C5D SCREW,HEX HEAD CAP
209 50008-12-C5D SCREW,HEX HEAD CAP
210 50008-7-C5D SCREW,HEX HEAD CAP
211 50008-14-C5D SCREW,HEX HEAD CAP
212 53300-526 TIE,CABLE (TY-RAP) (NS)
213 30171072 BRACKET,LUBE SWITCH
214 56506-16-16-S ELBOW,90′ EXT/ 37′ (NS)
总成号 118244 英文名称 KIT,TRAVELING EQUIPMENT ATTACHMENT
序号 部件号 英文名称
1 51405-18-S PIN,COTTER
2 76717 PEAR LINK
3 117076 BEAM,COUNTERBALANCE
4
5 112190-DWG DRAWING,COUNTERBALANCE PACKAGE
6 80390 CHAIN 9 LINK
7 80392 LINK CONNECTING
8 88484 SHACKEL(13.5 TON)
9 95030 DRAWING,COUNTERBALANCE PACKAGE(BECKET)
总成号80149 DRILLERS RECORDER TRANSDUCER KIT
1 79553 TRANSDUCER
2 80462 MOUNTING PLATE,TRANSDUCER
3 90837 VALVE,BALL 3 WAY
4 80427 SHUTOFF VALVE
5 80428 CONNECTOR,MALE-NPT/TUBE
6 80429 ELBOW,NPT/TUBE
7 80430 TUBING,POLYETHYLENE-1/4 OD
8 S6161-4-B TEE,INT PIPE-BRASS
9 90838 BRACKET,MOUNTING
10 S6700-4-2-B REDUCER,PIPE-BRASS
11 81599 J-BOX(12 TERM)
总成号 118217 英文名称 MOTOR ASSY,DRILL,AC(HELICAL)
序号 部件号 英文名称
1 SEE TABLE 1 AC MOTOR
2 51208-14 PIN,DOWEL
3 117939 PINION GEAR,HELICAL(MACHINING)
4 109554 HUB,BRAKE
5 50905-C WASHER,LOCK-REGULAR
6 30113618 LOUVER,MOTOR
7 50005-6-C5D SCREW,CAP-HEX HD
8 SEE TABLE 1 PLATE-BLOWER,DUCT(RIGHT)
9 SEE TABLE 1 PLATE-BLOWER,DUCT(LEFT)
10 120994 LOUVER,DRILL MOTOR
11 120995 COVER,LOUVER,DRILL MOTOR
12 110078-FL2 CABLE,SAFETY(FERRULE)(NOT SHOWN)
13 110078-L18 CABLE,SAFETY(∮.032)(NOT SHOWN)
14 30113619 SCREEN,LOUVER
15 110111 GASKET
16 115040 PINION INSTALLATION SUPPLIES
17 50005-12-C5 SCREW,CAP-HEX HD(UNC-2A)
18 53002-02-C PLUG,PIPE-SQ HD
总成号 30156835 PACKAGE,s-PIPE
序号 部件号 英文名称
1 50008-30-C5D SCREW,CAP-HEX HEAD
2 117063 S-PIPE,RH,WELDMENT,5000 PSI
3 30114855 S-PIPE,LH,WELDMENT,5000 PSI
4 116376 S-PIPE,WELDMENT(HERGULES)
5 116411 BRACKET,SERVICE LOOP/S-PIPE
6 108870-2 MOUNT,S-PIPE-TOP
7 108870-1 MOUNT,S-PIPE-BASE
8 117061 MOUNT,S-PIPE,RH(OUTSIDE GUARD)
9 114840 MOUNT,S-PIPE,LH(OUTSIDE GUARD)
10 92426 RUBBER,S-PIPE
11 50908-C WASHER,LOCK-REGULAR
12 56541-32 KIT,FLANCE
13 91921 PLUG,BLIND,3〞FIG 1002
14 91923 SEAL RING,3〞FIG 1002
15 30170449 WING NUT,3〞FIG 1002
16 50010-18-C5D SCREW,CAP-HEX HEAD
17 50910-C WASHER,LOCK-REGULAR
18 Z6001 LOCKWIRE(φ.051)
19 50912-C WASHER,LOCK-REGULAR
20 50012-16-C5D SCREW,CAP-HEX HEAD
21 50012-30-C5D SCREW,CAP-HEX HEAD
22 107714 MOUNT,COMPOSITE CABLE
23 78002 CLAMP,SERVICE LOOP BRACKET
24 50012-13-C5D SCREW,CAP-HEX HEAD
25 50008-16-C5D SCREW,CAP-HEX HEAD
26 50908-c WASHER,LOCK-REGULAR
27 117063-7500 S-PIPE,RH,WELDMENT,7500 PSI(OUTSIDE,GUARD)
28 30114855-7500 S-PIPE,LH,WELDMENT,7500 PSI(OUTSIDE GUARD)
29 114833 SEAL RING,4〞FIG 1002
30 81158 WING NUT,4〞FIG 1002
总成号 110068 RESERVOR,HYDRAULIC OIL ASSEMBLY
1 110067 RESERVOR,HYDRAULIC OIL
2 110191-500 BLADDER,RESERVOIR (4 GALLONS)
3 110191-500 BLADDER,RESERVOIR (5 GALLONS)
4 111915 COVER TOP,RESERVOIR
5 110132 GASKET
6 51300-038-B O-RING
7 50004-8-SD SCREW,CAP-HEX HEAD (UNC-2A)
8 50004-5-SD SCREW,CAP-HEX HEAD (UNC-2A)
9 50904-C WASHER,LOCK-RECULAR
10 107865-16 STRAINER,SUMP
11 56506-16-16S ELBOW,90°EXT/37°
12 53415 CAP,PLASTIC PIPE 1 1/16 SAE
13 53406 CAP,PLASTIC PIPE 9/16 SAE
14 53408 CAP,PLASTIC PIPE 1 5/16 SAE
15 71613 RESERVOIR BREATHER
16 108119-16B SIGHT GAGE
17 53000-12-S PLUG,PIPE
18 30113165 VALVE,RELIEF-POPOFF
19 56506-12-12S ELBOW,90°EXT/37°
20 56506-8-6-S ELBOW,90°EXT/37°
21 110078-FL2 CABLE,SAFTY(FERRULE) (NOT SHOWN)
22 110078-F18 CABLE,SAFTY(∮.032) (NOT SHOWN)
23 82570 ADHESIVE,RUBER
总成号(121442) 英文名称
序号 部件号 英文名称
1 109505-4 BAIL,500 TON-88.0” LONG
2 109505-3 BAIL,500 TON-120.0” LONG
3 109505 PIN,BAIL (CARRIAGE)
4 110123 RETAINER,BAIL PIN (CARRIAGE)
5 109507 BUSHING,BAIL PIN
6 53201 FITTING,GREASE-.125-27NPT
7 50012-20-C50 SCREW,HEX HEAD CAP
8 50008-9-C50 SCREW,HEX HEAD CAP
9 50908-C WASHER,LOCK-REGULAR
10 50912-C WASHER,LOCK-REGULAR
11 110077 LUG,COUNTERBALANCE
12 110070 BUTTON,COUNTERBALANCE
13 Z6000.9 LOCKWIRE .047
14 Z6001 LOCKWIRE .051
总成号 30123290 WASH PIPE ASSMBLY
序号 部件号 英文名称
1 30123563 BOX,PACKING ASSY,3″WASH PIPE
2 123284 NUT,3″WASH PIPE
3 123285 SPACER,UPPER,3″WASH PIPE
4 30123286 SPACER,MIDDLE,3″WASH PIPE
5 30123287 SPACER,LOWER,3″WASH PIPE
6 30123288 RING,HOLDING,3″WASH PIPE
7 30123289 PIPE,WASH-3 IN. BORE(HARD)
8 123292-2 PACKING SEAL KIT(5 PER SET)
9 51300-348-F O-RING
10 30122562 RING,SNAP
11 53219-1 FITTING,GREASE- STRAIGHT EXT.
12 30123564 SCREW,SOCKET HD-DOG NOSE
13 DELETED
14 56005-1 GREASE,GE-MTR(SHELL/TE ON)
15 86268 DESSICANT
16 DELETED
17 30123289-TC PIPE,WASH-3 IN. BORE(HARD)
18 123292-3 PACKING SEAL KIT(5 PER SET)
总成号 117603 英文名称 PUMP ASSEMBLY,GEARBOX LUBRICATION
序号 部件号 英文名称
1 117575 ADAPTER PLATE,LUBE PUMP
2 117575-1 ADAPTER PLATE,LUBE PUMP
5 30156326-36S MOTOR,HYDRAULIC,LOW-SPEED/HIGH-TORQUE
6 109567-H203 P50 PUMP(GEAR HOUSING)
7 109567-G20 P50 PUMP(GEAR SET )
8 109567-B P50 PUMP(ROLLER BEARING)
9 109567-E P50 PUMP(END COVER)
10 109567-S P50 PUMP(BODY SEAL)
11 109567-T P50 PUMP(THRUST PLATE)
13 50910-C WASHER,LOCK-REGULAR
14 108465-24 PLUG,SHIPPING SAE O-RING PORT
15 108119-16B SIGHT GAGE
16 109579 ADAPTER,MOTOR/PUMP
18 56519-16-16-S ELBOW,O-RING BOSS /37″
19 56529-10-8-S CONNECTOR,O-RING BOSS/37″
21 53000-16-C PLUG,EXT PIPE-C’SUNK HEX
23 71033 GASKET
25 50006-10-C5D SCREW,CAP-HEX HEAD
27 50006-40-C5D SCREW,CAP-HEX HEAD
28 50906-C WASHER,LOCK-REGULAR
29 53408 PLUG,PLASTIC PIPE CLOSURE
30 53418 PLUG,PLASTIC PIPE CLOSURE
31 Z6001 LOCKWIRE(∮.051)
总成号 117603 英文名称 SHOT PIN ASSEMBLY
序号 部件号 英文名称
1 94522-1EN VALVE,RELIEF
2 117830 GEAR,PINON
3 30118157 CAP,SHOT PIN
4 118155 BASE,SHOT PIN
5 117831 SHOT PIN
6 110056 ROD SEAL ASSEMBLY
7 30112527 COVER,SHOT PIN
8 110061-326 ROD SEAL ASSEMBLY
9 50008-10-C50 SCREW,CAP,HEX HEAD
10 50908-C WASHER,LOCK,REGULAR
11 118563 SLEEVE,SHOT PIN
12 30112526 BEARING,SHOT PIN
13 51402-10-S PIN,COTTER
14 114375-1 HYDRAULIC MOTOR
15 110163-2 MANIFOLD,DIRECT MOTOR MOUNT,DUAL PORT
16 S0004-05-C50 SCREW,CAP,HEX HEAD
17 Z6001 LOCKWIRE .050 DIA
18 50005-20-C50 SCREW,CAP,HEX HEAD
19 50905-C WASHER,LOCK,REGULAR
20 50904-C WASHER,LOCK,REGULAR
21 51300-226-8 O-RING
22 110078-L18 CABLE,SAFETY
23 110078-FL2 CABLE,SAFETY(FERRULE)
24 56529-6-6-S CONNECTOR,O-RING BOSS /37″
25 94520-1AN VALVE,RELIEF
26 56544-6-S CAP,FEMALE 37″ SEAT
27 50008-14-C50 SCREW,CAP,HEX HEAD
28 51212-10 PIN,DOWEL
29 53000-1-S PLUG,EXTERNAL PIPE C’SUNK HEX
30 56519-6-6-S ELBOW,O-RING BOSS/37″
31 93024-4SAE FITTING,TEST
32 118157-1 CAP,SHOT PIN
33 56555-6-6-S TEE 37″/37″/O-RING BOSS
34 93024-6JIC TEST FITTING
总成号 114174 英文名称 ASSY，MANIFOLD,UL
序号 部件号 英文名称
1 109547-2 MANILOLD,TDS-9
2 127908-J2 SOLENOID VALVE,3-POS,24VDC
3 127908-D2 SOLENOID VALVE,2-POS,24VDC
4 3D171921 REWORK MANUAL VALVE,3-POS
5 93667-M11 CAVITY PLUG,T-11A SHORT
6 94520-1NN RELIEF VALVE
7 94534-1CNX LOGIC CARTRIDGE
8 94536-14N CHECK VALVE
9 94536-23ON CHECK VALVE
10 94537-13ON PILOT-TO-CLOSE CHECK VALVE
11 98402-800D FLOW CONTROL VALVE
12 99353-1AN REDUCING/RELIEVING VALVE
13 107028-1ANB DIFFERENTIAL UNLOADING VALVE
14 107029-175N PILOT-TO-OPEN CHECK VALVE
15 107031-1AN RELIEF VALVE,VENTABLE
16 93667-M13 CAVITY PLUG,T-13A SHORT
17 109858-1AN REDUCING/RELIEVING VALVE
18 111664-1EN RELIEF VALVE,LOW FLOW
19
20 93024-4SAE TEST FITTING,SAE-4
21 93024-6SAE TEST FITTING,SAE-6
23 93018-08 ORIFICE PLUG,10-32 X.031
24 93018-14 ORIFICE PLUG,10-32 X.055
25 110844-18 ORIFICE PLUG,1/4 NPT X.071
27 87196-2-S SAE J514-2 HEX SOCKET PLUG
28 87196-4-S SAE J514-4 HEX SOCKET PLUG
29 87196-6-S SAE J514-6 HEX SOCKET PLUG
30 87196-8-S SAE J514-8 HEX SOCKET PLUG
31 87196-10-S SAE J514-10 HEX SOCKET PLUG
33 53000-1-S 1/16 NPT HEX SOCKET PLUG
34 53000-2-S 1/8 NPT HEX SOCKET PLUG
35 53000-4-S 1/4 NPT HEX SOCKET PLUG
36 53000-6-S 3/8 NPT HEX SOCKET PLUG
37 56544-4-S CAP,FEMALE 37″ SEAT
38 56544-6-S CAP,FEMALE 37″ SEAT
39 56544-12-S CAP,FEMALE 37″ SEAT
41 109106-69-S (-4 MOR8 / -6 MJIC ELBOW,TAPPED M5xBMM)
42 109105-10 PLUG,ORIFICE .39
44 50103-16-B SOCKET CAP SCREW 10-24×2.00
45 96079-A COVER,PLATE D03
46 99838-1 COVER,5UN CARTRIDGE,SERIES 1
47 53200-7471 LOCTITE,ACTIVATOR
48 110181 NAMEPLATE,C’BALANCE MODE
49 53200-545 HYDRAULIC PERMA-LOK
50 53200-242 LOCTITE,BLULOCK
51 56519-6-6-S ELBOW
52 56529-10-8-S CONNECTOR
53 56529-6-6-S CONNECTOR
54 56529-8-6-S CONNECTOR
55 56519-10-12-S ELBOW
56 56519-10-8-S ELBOW
57 56519-12-12-S ELBOW
58 56529-8-8-S CONNECTOR
59 56519-4-4-S ELBOW
60 56519-6-4-S ELBOW
61 56519-4-6-S ELBOW
62 128694-6-031 (-6 MOR8 / -6 MJIC ORIFICE FITTING)
63 56544-8-S CAP
64 56529-4-6-S CONNECTOR
65 93018-18 ORIFICE PLUG,10-32x.071
66 56518-6-6-S (-6 FJIC / -6 MJIC ,ELBOW)
67 50103-10-B SOCKET CAP SCREW 10-24×1 1/4
总成号 124538 CARRIACE ASSEMBLY,LEFT
序号 部件号 英文名称
1 124535 CARRIACE ASSEMBLY,LEFT,30.00”SETBACK
2 112875 PIN,BOGEY PIVOT
3 124537 BOGEY
4 51024-C WASHER,LOCK-1.5”
5 30155438 CAM FOLLOWER 6”DIA
6 30158767-04 BEARING,CAM FOLLOWER(MoGill号,CF-4-SB)
7 55324-C NUT,HEX-JAM﹙1.50-12 UNF-28﹚
8 51132-C WASHER,LOCK,HI-COLLAR,2# DIA
10 109944 BUSHING,FLANGED,2075 10
11 30157306 PIN,LINCH ￠.188
12 50512-C NUT,HEX SLOTTED
13 80569 NUT,JAM,2-12” UN-28
14 51716-24-C BOLT,SHOULDER SOCKET HD ﹙UNC-3A﹚
15 129375 BRACKET,ANGLE
16 50006-5-C5D SCREW,HEX HD,CAP
17 50912-C WASHER,LOCK-REGuLAR
18 126727-3 FERRULE BAR
19 51220-2 CABLE RETAINNING ∮.063 20” LONG
20 30152845 PIN
21 125727-1 PLATE
22 125727-2 PLATE
23 88710 STRAP
24 50108-10-CO SCREW,HEX HD. CAP ,1/2 UNC*1.25
25 50008-10-C5D SCREW,CAP-SOCKET HD.1/2 UNC*1.25
26 50908-C WASHER,LOCK-REGULAR
27 113370 STRAP,ACCUMULATOR,∮6″
28 50812-N-C WASHER,FLAT
29 124535-500 CARRIAGE,(LEFT),33.75″ SETBACK
30 124535-502 CARRIAGE,(LEFT),39.50″ SETBACK
31 51402-12-S PIN,COTTER
32 51219-2 FERRULE,CABLE
33 124535-503 CARRIAGE,(LEFT),41.00″ SETBACK
34 53201 FITTING,GREASE (1/8″-27 NPT)
总成号 124539 CARRIAGE ASSEMBLY,RIGHT
1 124536 CARRIAGE,(RIGHT),30.00″ SETBACK
2 112875 PIN,BOCEY PIXOT
3 124537 BOGEY
4 51024-C WASHER,LOCK-1.5″
5 30155438 CAM FOLLOWER,6″
6 30158767-04 BEARING,CAM FOLLOWER
7 55324-C NUT,HEX-JAM(1.50-12 UNF-28)
8 51132-C WASHER,LOCK,HI-COLLAR,2″ DIA
10 109944 BUSHING,FLANGED,2.75 ID
11 30157306 PIN,LINCH ∮.188
12 125727-Z PLATE
13 80569 NUT,JAM,2″-12 UN-2B
14 51716-24-C BOLT,SHOULDER SOCKET HD (UNC-3A)
15 53201 FITTING,GREASE (1/8″-27 NPT)
16 50512-C NUT,HEX-SLOTTED (UNF-28)
17 51219-2 FERRULE CABLE
18 125727-3 FERRULE BAR
19 51220-2 CABLE RETAINING ∮.063,20″ LONG
20 30152845 PIN
21 125727-1 PLATE
22 50812-N-C WASHER,FLAT
23 124536-500 CARRIAGE,(RIGHT),33.75″ SETBACK
24 124536-502 CARRIAGE,(RIGHT),39.50″ SETBACK
25 51402-12-5 PIN,COTTER
26 DELETED
27 124536-503 CARRIAGE,(RIGHT),41.00″ SETBACK
总成号 30157366 PIPE HANDLER PACKACE
序号 部件号 英文名称
1 30157288 TORQUE ARRESTOR ASSEMBLY
2 30158189 CRANK ASSEMBLY,LINK TILT
3 30158164 PIN,CRANK
4 59D44P230073 HOSE ASSEMBLY,CLAMP,PISTTON
5 59D44P230074 HOSE ASSEMBLY,CLAMP,ROD
6 119387 PIN,PIPE HANDLER
8 Z6001 SAFTY WIRE(φ.051)
9 110042 SHELL,ACUTATOR,IBOP
10 98898 CRANK ASSEMBLY,IBOP
11 107052 LOCK TAB
12 50008-14-C5D SCREW,CAP-HEX HEAD
13 30119592 CYLINDER,HYDRAULIC ASSEMBLY
15 118947 BAR,RETAINING
16 50008-11-C5D SCREW,CAP-HEX HEAD
17 30170445 LINK 1,COLLAPSIBLE
18 30170445 LINK 2,COLLAPSIBLE
19 51008-C WASHER,LOCK-HEAVY
20 50816-R-C5 WASHER,FLAT-REGULAR
21 50412-C NUT,HEX-HEAVY
22 51012-C WASHER,LOCK-HEAVY
23 118463-2 MANIFOLD,LINK TILT CYLINDER
24 51435-2D-5 PIN COTTER
25 59D43P170038 HOSE ASSEMBLY,HYDRAULIC CYLINDER,LINK TILT
26 59D44P170042 HOSE ASSEMBLY,HYDRAULIC CYLINDER,LINK TILT
27 30170045 PIN,RETAINER,COLLASIBLE LINK
28 50814-N-C WASHER,FLAT
29 56519-12-8-5 ELBOW,O-RING BOSS/37
32 112848 TOOL JOINT LOCK
33 59D24P170021 HOSE ASSEMBLY,IBOP CYLINDER
34 59D24P170024 HOSE ASSEMBLY,IBOP CYLINDER
35 30170509 TUBE ASSEMBLY,LINL ADAPTER/MANIFOLD
36 30170510 TUBE ASSEMBLY,LINL ADAPTER/MANIFOLD
37 30170511 TUBE ASSEMBLY,LINL ADAPTER/MANIFOLD
38 50514-C NUT,HEX-SLOTTED
39 59D24P17ND23 HOSE ASSEMBLY,HYDRAULIC CYLINDER,LINK TILT
40 59D25P17ND26 HOSE ASSEMBLY,HYDRAULIC CYLINDER,LINK TILT
41 30157317 BRACKET MOUNTING,LINK TILT MANIFOLD
42 50006-12-C5D SCREW,CAP-HEX HEAD
43 50906-C WASHER,LOCK-REGULAR
44 50006-36-C5D SCREW,CAP-HEX HEAD
45 51437-20 PIN,COLLER
46 50820-N-C WASHER,FLAT
47 51403-20 PIN,COLLER
48 50520-C NUT,HEX-SLOTTED
总成号 30157288 ASSY,TORQUE ARRESTOR PH-75
序号 部件号 英文名称
1 30157226 TORQUE ARRESTOR,PIPE HANDLER
2 30157278 CLAMP CYLINDER ASSEMBLY
3 30157225 YOKE,IBOP ACTUATOR
4 125594 CYLINDER ASSY,HYD,IBOP ACTUATOR
5 30157308 SPRING
6 30157294 BOTTOM PLATE
8 121979 TRUNNING BUSHING,CYL MOUNT
9 30157292 POST,SPRING
10 30172154 PIN,CYLINDER MOUNTING
11 30158766-1 PIN,PIVOT,YOKE
13 30157318-1 SPACER,SPRING
14 30157318-2 SPACER,SPRING
15 30157318-3 SPACER,SPRING
16 118844-16-8 BEARING,SELF LUB,1.00 ID×.75 LG
17 118844-16-12 BEARING,SELF LUB,1.00 ID×.50 LG
19 53208 FITTING,GREASE
20 118844-22-22 BEARING,SELF LUB,1.375 ID×.50 LG
21 50008-12-C5D SCREW,CAP,HEX HD
22 30172179 BAR,SAFETY,CLAMP CULINDER
23 50012-2D-C5D SCREW,CAP,HEX HD
24 30172825 PIN,PIVOT
25 51012-C WASHER,LOCK,HEAVY
26 50914-C WASHER,LOCK,REG
27 55214-C NUT,HEX,STD(UNF)
28 50908-C WASHER,LOCK REG
29 Z6001 LOCKWIRE(φ.051)
30 50216-C NUT,HEX HD,STD
32 71847 ROLLER
33 51402-12 PIN,COTTER
34 50512-C NUT,HEX HD,SLOTTED
36 56519-8-6-S ELBOW,O-RING BOSS/37
37 51604-6-C PIN,ROLL,φ.250×.75 LG
38
39 30114259 PIN,SAFETY
41 30157297 HANGER,CLAMP CYLINDER
42 30157426 SCREW,DRILLED SHANK
43 51220-2 CABLE,φ.063×24.0 LG,NYLON COSTED
44 51219-2 FERRULE,CABLE
45 53406 PLUG,PLASTIC PIPE CLOSURE
46 50516-S NUT,HEX-SLOTTED
47 51435-16-S PIN,COTTER
总成号 30157287 CLAMP CYLINDER ASSY PH75
序号 部件号 英文名称
1 30157221 BODY,CLAMP CYLINDER
2 124902 GATE
3 12820 PISTON
4 11075 CYLINDER HEAD
5 125013 PIN,HINGE
6 11085 CYLINDER HEAD
7 72219 SEAL,PISTON
8 72220 SEAL,ROD
9 72221 RING,WIPER
10 50905-C WASHER,LOCK,REG
11 50005-20-C5D SCREW,HEX HD
12 50908-C WASHER,LOCK,REG
13 118511 MANIFOLD ASSEMBLY,CLAMP CYLINDER
14 Z6001 LOCKWIRE,.051 DIA
15 53201 FITTING,GREASE
16 30124898 STABILIZER,FRONT
17 117989 SCREW,HEX HD,DRILLED SHANK
18 50516-C NUT,HEX,SLOTTED
19 50816-N-C WASHER
20 51403-14-5 PIN,COTTER
21 120739 RETAINER,HINGE
22 50008-10-C5D SCREW,HEX HD
23 30158590 LINER,STABILIZER
25 79179 SPRING,DIE
26 51710-5-C BOLT,SHOULDER,SOC HD
27 30125052 JAW ASSY,NC50-5 1/2 FH(φ6.25-7.50)
28 125158 STAB,GUIDE ASSY,NC50-5 1/2 FH(SET)
29 16532 KEY
30 50108-14-C SCREW,CAP,SOC HEAD
31 51108-C WASHER,LOCK,HI COLLAR
32 50912-C WASHER,LOCK,REG
33 50012-16-C5D SCREW,HEX HD
总成号 30157622 KIT,TOOL JOINT ADAPTER,PH-75
序号 部件号 英文名称
1 125157 STABBING GUIDE ASSEMBLY,φ4.75-φ6.00 O.D. TOOL JOINT
2 125158 STABBING GUIDE ASSEMBLY,φ6.25-φ7.50 O.D. TOOL JOINT
3 125159 STABBING GUIDE ASSEMBLY,φ7.50-φ8.63 O.D. TOOL JOINT
4 30173442 STABBING GUIDE ASSEMBLY,φ3.50-φ4.31 O.D. TOOL JOINT
5 125051 JAW ASSEMBLY,φ4.75-φ6.00 O.D. TOOL JOINT
6 125052 JAW ASSEMBLY,φ6.25-φ7.50 O.D. TOOL JOINT
7 125053 JAW ASSEMBLY,φ7.50-φ8.62 O.D. TOOL JOINT
8 30173233 JAW ASSEMBLY,φ3.50-φ4.31 O.D. TOOL JOINT
9 30157433 SAVER SUB,6 5/8 REG×6 5/8 F.H.(PH75)
10 123221-1 SAVER SUB,6 5/8 REG×5 1/2 F.H.
11 76666-2 SAVER SUB,6 5/8 REG×NC50
12 78658-1 SAVER SUB,6 5/8 REG×NC46
13 118952-1 SAVER SUB,6 5/8 REG×NC40
14 118953-1 SAVER SUB,6 5/8 REG×HT40
15 118954-1 SAVER SUB,6 5/8 REG×NC38
16 129089-375 SAVER SUB,6 5/8 REG×HT55
17 30157411 SAVER SUB,6 5/8 REG×XT39
18 30172182 SAVER SUB,6 5/8 REG×XT57
19 30173142 SAVER SUB,6 5/8 REG×PH-6,3 1/2 OD
26 85705 CORSSOVER SUB,6 5/8 REG×6 5/8 F.H.
27 79410-4 CORSSOVER SUB,6 5/8 REG×6 1/2 F.H.
28 79410-3 CORSSOVER SUB,6 5/8 REG×NC50
29 115595 CORSSOVER SUB,6 5/8 REG×NC46
30 120822 CORSSOVER SUB,6 5/8 REG×NC40
31 114542-600 CORSSOVER SUB,6 5/8 REG×HT40
32 110852 CORSSOVER SUB,6 5/8 REG×NC38
33 129090-375 CORSSOVER SUB,6 5/8 REG×HT55
34 30157412 CORSSOVER SUB,6 5/8 REG×XT39
35 30172183 CORSSOVER SUB,6 5/8 REG×XT57
36 30173144 CORSSOVER SUB,6 5/8 REG×PH-6,3 1/2 OD
45 50108-20-C SCREW,SOCKET HEAD CAP-.500-13 UNC×3.00 LG
46 50108-16-C SCREW,SOCKET HEAD CAP-.500-13 UNC×1.50 LG
47 50108-12-C SCREW,SOCKET HEAD CAP-.500-13 UNC×2.00 LG
48 50108-24-C SCREW,SOCKET HEAD CAP-.500-13 UNC×2.50 LG
53 51108-C WASHER,LOCK-HIGH COLLAR φ.500 NOM
54 16532 KEY
总成号(121341) 英文名称
序号 部件号 英文名称
1 121340 ROTATING LINK ADAPTER 500 TON
2 117833-500 STEM
3 51216-12 DOWEL 1.0 * 1.50
4 117829 GEAR,ROTATING LINK ADAPTER
5 51300-273-B O-RING
6 51300-381-B O-RING
7 30119319 GLYD RING ROTARY 11.000 ROD
8 30119357 RING,THRUST
9 117826 PISTON RING
10 30119143 GLYD RING ROTARY 11.500 ROD
11 118375 GLYD RING ROTARY 10.000 ROD
12 77039 SEAL
13 114594 BOLT,CATCH LINK
14 50520-C NUT,HEX-SLOTTED
15 50820-R-C WASHER,FLAT
16 51405-24 PIN,COTTER
17 50012-20-C5D SCREW,HEX HD
18 50912-C WASHER,LOCK
19 119547 SEAL,WIPER
20 30117775 RETAINER RING
21 119358 BUSHING,TURCITE
22 53201 FITTING,GREASE
23 53000-4-C PLUG,PIPE,C’SUNK HEX
24 Z6001 LOCKWIRE,.051
25 56529-8-8-S CONNECTOR,O-RING BOSS/37′
26 53408 CAP
27 56531-8-S PLUG,O-RING BOSS
28 115176 BISHING
29 112754-130 BEARING,FLANCED
30 53002-12-C PLUG,PIPE,SQ,HEAD
31 119369 RETAINER ,OIL SEAL
32 124029 SHAFT,PIVOT-LOCKING PIN
33 51222-05-12 PIN,SPIRAL
34 53200-271 LOCKING,COMPOUND (RED)
35 119124 STOP
36 112754-116 BUSHING,FLANCD
37 50020-24-C50 SCREW,CAP-HEX HD
38 50320-C NUT,HEX-JAM
39 50516-C NUT,HEX-SLOTTED
40 51437-20-S PIN,COTTER
41 56629-8-6-S CONNECTOR,O-RING BOSS/37′
42 56629-8-4-S CONNECTOR,O-RING BOSS/37′
43 56519-8-6-S ELBOW,O-RING BOSS/37′
44 53406 CAP
45 53405 CAP
46 53250 RELIEF VALVE
30158189 CRANK,ASSEMBLY
序号 部件号 英文名称
1 30158188 CRANK,ASSEMBLY
2 118844-16-24 BUSHING,FIBREGLIDE
总成号 30157288 ASSY,TORQUE ARRESTOR PH-75
序号 部件号 英文名称
1 30157226 TORQUE ARRESTOR,PIPE HANDLER
2 30157278 CLAMP CYLINDER ASSEMBLY
3 30157225 YOKE,IBOP ACTUATOR
4 125594 CYLINDER ASSY,HYD,IBOP ACTUATOR
5 30157308 SPRING
6 30157294 BOTTOM PLATE
8 121979 TRUNNING BUSHING,CYL MOUNT
9 30157292 POST,SPRING
10 30172154 PIN,CYLINDER MOUNTING
11 30158766-1 PIN,PIVOT,YOKE
13 30157318-1 SPACER,SPRING
14 30157318-2 SPACER,SPRING
15 30157318-3 SPACER,SPRING
16 118844-16-8 BEARING,SELF LUB,1.00 ID×.75 LG
17 118844-16-12 BEARING,SELF LUB,1.00 ID×.50 LG
19 53208 FITTING,GREASE
20 118844-22-22 BEARING,SELF LUB,1.375 ID×.50 LG
21 50008-12-C5D SCREW,CAP,HEX HD
22 30172179 BAR,SAFETY,CLAMP CYLINDER
23 50012-2D-C5D SCREW,CAP,HEX HD
24 30172825 PIN,PIVOT
25 51012-C WASHER,LOCK,HEAVY
26 50914-C WASHER,LOCK,REG
27 55214-C NUT,HEX,STD(UNF)
28 50908-C WASHER,LOCK REG
29 Z6001 LOCKWIRE(φ.051)
30 50216-C NUT,HEX HD,STD
32 71847 ROLLER
33 51402-12 PIN,COTTER
34 50512-C NUT,HEX HD,SLOTTED
36 56519-8-6-S ELBOW,O-RING BOSS/37
37 51604-6-C PIN,ROLL,φ.250×.75 LG
38
39 30114259 PIN,SAFETY
41 30157297 HANGER,CLAMP CYLINDER
42 30157426 SCREW,DRILLED SHANK
43 51220-2 CABLE,φ.063×24.0 LG,NYLON COSTED
44 51219-2 FERRULE,CABLE
45 53406 PLUG,PLASTIC PIPE CLOSURE
46 50516-S NUT,HEX-SLOTTED
47 51435-16-S PIN,COTTER
总成号 30157287 CLAMP CYLINDER ASSY PH75
序号 部件号 英文名称
1 30157221 BODY,CLAMP CYLINDER
2 124902 GATE
3 12820 PISTON
4 11075 CYLINDER HEAD
5 125013 PIN,HINGE
6 11085 CYLINDER HEAD
7 72219 SEAL,PISTON
8 72220 SEAL,ROD
9 72221 RING,WIPER
10 50905-C WASHER,LOCK,REG
11 50005-20-C5D SCREW,HEX HD
12 50908-C WASHER,LOCK,REG
13 118511 MANIFOLD ASSEMBLY,CLAMP CYLINDER
14 Z6001 LOCKWIRE,.051 DIA
15 53201 FITTING,GREASE
16 30124898 STABILIZER,FRONT
17 117989 SCREW,HEX HD,DRILLED SHANK
18 50516-C NUT,HEX,SLOTTED
19 50816-N-C WASHER
20 51403-14-5 PIN,COTTER
21 120739 RETAINER,HINGE
22 50008-10-C5D SCREW,HEX HD
23 30158590 LINER,STABILIZER
25 79179 SPRING,DIE
26 51710-5-C BOLT,SHOULDER,SOC HD
27 30125052 JAW ASSY,NC50-5 1/2 FH(φ6.25-7.50)
28 125158 STAB,GUIDE ASSY,NC50-5 1/2 FH(SET)
29 16532 KEY
30 50108-14-C SCREW,CAP,SOC HEAD
31 51108-C WASHER,LOCK,HI COLLAR
32 50912-C WASHER,LOCK,REG
33 50012-16-C5D SCREW,HEX HD
30125052
部件号英文名称
1 16401-2 PIN,COTTER
2 124925 NUT,HEX SLOTTED
3 124935 BOLT,RETAINER
4 122112 RETIANER,DIE
5 50508-C JAW
6 51402-16-5 DIE,TONG
总成号 118463 英文名称 MANIFOLD ASSY LINK TILT CYLINDER
序号 部件号 英文名称
1 SEE TABLE MANIFOLD,LINK TILT CYLINDER
118172-BSCSTEEL
118172-1S STEEL
118172-2ALUMINUM
2 93547-1B200N CHECK VALVE,PILOT TO OPEN(CKCB-XCN)
3 30173386 VALVE,COUNTERBALANCE(CBCA-LHN)
4 56519-4-4-S ELBOW,O-RING BOSS/37″,-4
5 93024-4SAE TEST FITTING,SAE-4
6 94042-36 OFIFICE,1/8NPTx∮.142
7 93018-08 ORIFICE,#10-32UNFx∮.031
8 87196-2-S PLUG,O-RING,-2
9 56529-8-8-S CONNECTOR,O-RING BOSS/37″,1/2″
10 56519-8-8-S ELBOW,O-RING BOSS/37″,-8
11 112809-08 CAP,SHIPPING,THREADED,-8
12 53200-545 LOCTITE,HYDRAULIC
13 112809-04 CAP,SHIPPING,THREADED,-4
14 87196-8-S PLUG,O-RING,-8
15 99838-1 COVER,SUN CARTRIDGE,SERIES 1
序号 部件号 英文名称
1 119416 CYLINDER,HYDRAULIC
2 119732 CLEVIS
3 30119546 PIN,CLEVIS
4 119731 RETAINER
5 50004-8-C5D SCREW,CAP-HEX HEAD
6 50904-C WASHER,LOCK
7 51635-12-C PIN,ROLL
8
9 30172154 PIN,CYLINDER MOUNTING
10 50512-C NUT,HEW SLOTTED
11 51435-16 PIN,COTTED
12 Z6008.1 LOCKWIRE .031Ф
总成号 124994 J-BOX A55EMBLY
1 124993 J-BOX (MACHINING)
2 78927-3 SUPPORT RAIL
3 78927-6 SUPPORT RAIL
4 123294-2 TERMINAL ASSEMBLY
5 123294-3 TERMINAL ASSEMBLY
6 123220 TERMINAL ASSEMBLY (GND BUS BAR)
7 78916 FIXING NUT AND SCREW(METRIC)
8 96371 SCREW,FLAT HEAD(METRIC)
9 50067-040-F-07 SCREW,CAP-HEX (METRIC)
10 50803-N-S WASHER,FLAT
11 50649-60 SCREW,PAN HEAD,10-32
12 30158431 BREATHER DRAIN
13 30173254-08 FILLISTER HEAD SCREW,DRILLED
14 Z5001-8 LOCK WIRE ∮.032
总成号 125158 STABBING GUIDE ASSY,∮6.25-7.50 TOOL JOINT
1 125057 GUIDE,STABBING,CLAMP CYL
2 125059 GUIDE,STABBING,GATE
3 76442 GUIDE,ARM
4 76443 SPRING
5 76445 RETAINER
6 50008-13-C5D CAP SCREW,HEX DRILLED HEAD
7 50810-N-C WASHER,FLAT,NARROW
8 50908-C WASHER,LOCK REG SERIES
9 51402-8-5 PIN,COTTER
10 Z6001 WIRE,LOCK, .051 DIA
11 76398 PIN
总成号 80149 DRILLERS RECORDER TRANSDUCER KIT
1 79553 TRANSDUCER
2 80462 MOUNTING PLATE,TRANSDUCER
3 90837 VALVE,BALL 3 WAY
4 80427 SHUTOFF VALVE
5 80428 CONNECTOR,MALE-NPT/TUBE
6 80429 ELBOW,NPT/TUBE
7 80430 TUBING,POLYETHYLENE-1/4 OD
8 S6161-4-B TEE,INT PIPE-BRASS
9 90838 BRACKET,MOUNTING
10 S6700-4-2-B REDUCER,PIPE-BRASS
总成号 114706 英文名称 ASSY ，LOWER IBOP
序号 部件号 英文名称
1 114705 BODY,IBOP 5 1\4 SHORT
2
3 89141-7 CRANK,OPER.-RH
4 89453-7 CRANK,OPER.-RH
5 89141-8 SEAL,CROWN
6 89453-8 SEAL,CROWN
7 90441-7 SLEEVE,CRANK
8 89141-11 O-RING
9 89453-11 O-RING
10 89141-12 BACK-UP RING
11 89453-12 BACK-UP RING
12 99497 SET,SEAT/BALL
13 99501 SET,SEAT/BALL(H2S)
14 89141-9 SPRING,WAVE
15 89453-9 SPRING,WAVE
16 89141-3 O-RING
17 89453-3 O-RING
18 89141-13 BACK-UP RING
19 89453-13 BACK-UP RING
20 90441-9 O-RING
21 89453-16 O-RING
22 90441-10 BACK-UP RING
23 89453-17 BACK-UP RING
24 91137-12 NYLON PLUG
25 89141-1 RETAINING RING
26 89453-1 RETAINING RING(H2S)
27 77369-5 THREAD PROTECTOR-BOX(NOT SHOWN)
28 77369-6 THREAD PROTECTOR-PIN(NOT SHOWN)
29 114792 BODY,IBOP 5 1\4 SHORT(NAM)
30 114791 BODY,IBOP 5 1\4 SHORT(GLAND POCKETS ONLY)
110103 upper ibop
1 110102 body ,upper ibop
2 body ,upper ibop
3 110118 crank oper-rh
4 114902 crank oper-rh
5 110128 crank oper-lh
6 114901 crank oper-lh
7 65060690 seal,crown
8 65060691 seal,crown
9 98895 sleeve,crank
10 65060791 o-ring
11 65060793 o-ring
12 65060792 back-up ring
13 65060794 back-up ring
14 99500 set,seat/ball
15 98966 set,seat/ball
16 65021490 spring,wave
17 65021491 spring,wave
18 65021190 o-ring
19 65021192 o-ring
20 65021191 back-up ring
21 65021193 back-up ring
22 96438 stablizer,seal ring
23 65060695 seal,u-cup
24 65060696 seal,u-cup
25 65060196 o-ring
26 65060198 o-ring
27 65060197 back-up ring
28 65060199 back-up ring
29 65060492 nylon plug
30 65060191 retaining ring
31 65060192 retaining ring(H2S)
32 650210B0 plug ,pressure
33 65020193 thread protector
118511
1 112489-2 MANIFOLD,CLAMP CYLINDER
2 93024-4SAE FITTING,TEST-SAE-4
3 94537-130N CARTRIDGE,CHECK (PILOT TO CLOSE) (CODA-XCN)
4 109302-130NC CARTRIDGE,FLOW CONTROL (CNCC-XCN-.047)
5 56557-8-8-S ELBOW,45′ O-RING BOSS/37′
6 87196-2-S PLUG,SAE-2,HEX SOCKET
7 87196-6-S PLUG,SAE-6,HEX SOCKET
8 87196-8-S PLUG,SAE-8,HEX SOCKET
9 53408 PLUG,PLASTIC PIPE CLOSURE
10 107303-1-8 FLANGE PROTECTOR,SAE J518
11 51300-210-B O-RING,SIZE -210
总成号(120546) 英文名称
序号 部件号 英文名称
1 121732 WELDMENT,ENCLOSURE
2 121010-1 GASKET,ENCLOSER
3 122627-46 REMOTE 24 DI/8DO,24VDC
4 122627-45 REMOTE 4 ANALOG INPUT
5 122627-47 REMOTE 4 NAALOG OUTPUT
6 122627-58 REMOTE I/O BASE,DIGITAL
7 122627-57 REMOTE I/O BASE,ANALOG
8 122627-34 BUS CONNECTOR (PROFIBUS)
9 96290 REG.MODULE,+24VDC/+5VDC
10 96218-3 METER,RPM.0-10VDC (0-250 RPM)
11 116551 RHEOSTAT ASSY,THROTTLE
12 81736-2 POTENTIOMETER,10K
13 87708-46 POTENTIOMETER OPERATOR
14 87708-67 PUSHBOTTON,E-STOP.MUSHROOM
15 87708-33 SWITCH,SEL.-3 POS.SPRING RTN TO RIGHT
16 87708-30 SWITCH,SEL.-3 POS.SPRING RTN TO CENTER
17 87708-02 SWITCH,PUSHBUTTON
18 87708-40 INDICATING LIGHT,AMBER
19 87708-38 INDICATING LIGHT,RED
20 87708-44 INDICATING LAMP,2 WATT
21 56621-18-8 WIRE,STANDED,HOOK-UP
22 87975 CABLE,2 TWISED PAIR
23 56610-01 TERMINAL,WIRE-SPADE
24 78725 FERRULE,20 AWG.
25 78725-03 FERRULE,18 AWG.
26 78725-05 FERRULE,12 AWG.
27 122443-9-H CABLE, PIGTAIL,5 TSP,CONNECTORIZED
28 83444-05 GLAND,25mm,ARMORED
29 86871-25 WASHER,SEALING,25mm
30 86872-25-S LOCKWASHER,INT STAR,25mm
31 78317-25 LOCKNUT,25mm
32 125041 H-RAIL,33 INCH
33 85038-UL-2.5 TERMINAL BLOCK
34 85039 ENDPLATE,TERMINAL
35 90153 END CLAMP
36 85145-6-001 MARKERS,HORIZONTAL (#1-10)
37 85145-6-011 MARKERS,HORIZONTAL (#11-20)
38 85145-6-021 MARKERS,HORIZONTAL (#21-30)
39 50649-68 SCREW,MACHINE,PAN HD.10-32
40 50649-61 SCREW,MACHINE,PAN HD.10-32
41 50803-R-S WASHER,FLAT,NO.10
42 50903-S WASHER,LOCK,NO.10
43 50202-S NUT.HEX.8-32
44 50802-R-S WASHER,FLAT,NO.8
45 50902-S WASHER,LOCK,NO.8
46 50604-6-S SCREW,MACHINE,FLAT HD,1/4-20
47 50204-B NUT,HEX,1/4-20
48 50202-B NUT,HEX,8-32
49 96206-3 LABEL,NFPA 496 Z PURGE
50 110869 RIVET,SEALING,CLOSED END
51 81778 SWITCH,DIFFERENTIAL PRESSURE
52 88493 ELBOW,FEMALE,1/4 *1/8
53 88491 ELBOW,MALE,1/4 * 1/8
54 52002-12-B NIPPLE,PIPE,1/8 NPT * 1.5 LNG
55 80430 TUBING,1/4
56 53227 TEFLON TAPE
57 78910-BSC RTV.108,CLEAR
58 53200-242 COMPOUND,LOCKING (BLUE)
59 53200-454 COMPOUND,LOCKING (CLEAR)
60 88650 GREASE,LITHIUM BASED
61 96219-10 METER,TOQUE,TDS-10S (O-40K FT LB)
62 96219-11 METER,TORQUE,TDS-9S/-11S (O-60K FT LB)
63 30121239-BSC NAMEPLATE,VDC.STANDED
64 30121239-2 NAMEPLATE,VDC.VERTICALLY MOUNTED
65 30121239-3 NAMEPLATE,VDC.WITH STANJUMP
66 30121239-4 NAMEPLATE,VDC.WITH ELEVATOR AND STANDJUMP
67 87708-36 SWITCH,SEL.-3 POS.MANIFOLD
68 87708-26 SWITCH,SEL.-2 POS..MANIFOLD
69 87124 HORN,24 VDC
70 88663 J-BOX,HORN
71 88050-200228 GROMMENT,5/8 I.D.
72 55203-S NUT,HEX,10-32
73 53001 PLUG,PIPE,1/8-27 NPT
74 30121239-7 NAMEPLATE,VDC.VERTICAL,ELEVATOR AND STANDJUMP
128923 ELECTRICAL PACKAGE
序号 部件号 英文名称
1 SEE TABLE 2 PUMP/MOTOR ASSY
2 SEE TABLE 1 MANIFOLD ASSY
3 124994 J-BOX ASSEMBLY
4 115202 NAMEPLATE,CONNECTOR WARING
5 112711 PLATE,MOTOR
6 110143 PLATE,MOUNTING-J-BOX/MANIFOLD
7 DELETED
8 53301-10-6 SCREW,DRIVE-TYPE U
9 83444-06 GLAND,EXE ARMOURED CABLE
10 83095-1 PRESSURE SWITCH,IBOP
11 87541-1 PRESSURE SWITCH,OIL
12 76841 PRESSURE SWITCH,AIR
13 56625-2.5-04 CABLE,SHIPBOARD-MULYICORE
14 56625-1.5-07 CABLE,SHIPBOARD-MULYICORE
15 56625-1.5-03 CABLE,SHIPBOARD-MULYICORE
16 56626-03 CABLE,SHIPBOARD-TWISTED/SHIELDED
17 110076 CABLE,4/0-ARMOURED ＆ JACKETED
18 83444-01 GLAND,Eexe ARMOURED CABLE,20mm
19 83444-05 GLAND,Eexe ARMOURED CABLE,25mm
20 129991-07 GLAND,Eexe ARMOURED CABLE,50mm
21 78317-20 LOCKNUT
22 78317-25 LOCKNUT
23 78317-50 LOCKNUT
24 86871-20 WASHER,NYLON SEALING
25 86871-25 WASHER,NYLON SEALING
26 86871-50 WASHER,NYLON SEALING
27 56600-12-8 BUSHING,REDUCING,ELECTRICAL
28 56600-16-12 BUSHING,REDUCING,ELECTRICAL
29 50004-9-C5D SCREW,CAP-HEX HEAD
30 50006-10-C5D SCREW,CAP-HEX HEAD
31 50010-44-C5D SCREW,CAP-HEX HEAD
32 50008-10-C5D SCREW,CAP-HEX HEAD
33 50010-10-C5D SCREW,CAP-HEX HEAD
34 50008-20-C5D SCREW,CAP-HEX HEAD
35 50006-8-C5D SCREW,CAP-HEX HEAD
36 50004-8-C5D SCREW,CAP-HEX HEAD
37 50005-4-C5D SCREW,CAP-HEX HEAD
38 DELETED
39 50010-52-C5D SCREW,CAP-HEX HEAD
40 50606-8-C SCREW,CAP-HEX HEAD
41 50012-16-C5D SCREW,CAP-HEX HEAD
42 50912-C WASHER,LOCK-REGULAR
43 50910-C WASHER,LOCK-REGULAR
44 50906-C WASHER,LOCK-REGULAR
45 50904-C WASHER,LOCK-REGULAR
46 50908-C WASHER,LOCK-REGULAR
47 86872-25-S LOCKWASHER,INTERNAL STAR
48 86872-20-S LOCKWASHER,INTERNAL STAR
49 86872-50-S LOCKWASHER,INTERNAL STAR
50 86625-01 GLAND,CABLE – JACKETED (UL)
51 86625-02 GLAND,CABLE – JACKETED (UL)
52 110078-FL2 CABLE, SAFETY (FERRULE) (NOT SHOWN)
53 110078-L18 CABLE, SAFETY (Ф.032) (NOT SHOWN)
54 Z6000.9 LOCKWIRE Ф0.47 (NOT SHOWN)
55 Z6001 LOCKWIRE Ф0.51 (NOT SHOWN)
56 SEE TABLE 3 BRKT,SERIVCE LOOP-RIGHT HAND
57 SEE TABLE 3 BRKT,SERIVCE LOOP-LEFT HAND
58 115299 ENCODER,DIGITAL, TDS-9S
59 50012-16-C5D SCREW,CAP-HEX HEAD
60 50912-C WASHER,LOCK-REGULAR
61 58908-B NIPPLE,CLOSE
62 56606-8 ELBOW,CAPPED
63 127386 3M POTTING COMPOUND
64 50905-C WASHER,LOCK-REGULAR
65 56541-32 KIT,SPLIT FLANGE (INCLUDES HARDWARE)
66 Z6000.8 LOCKWIRE Ф0.31 (NOT SHOWN)
67 56600-16-12 REDUCER,1″NPT×25mm
68 116427 STUD,GROUNDING
69 53219-3 FITTING,GREASE-STRAIGHT EXTENDED
70 50803-R-C WASHER,FLAT-REG
71 DELLETED
72 50006-10-C5D SCREW,CAP-HEX HEAD
73 53200-242 COMPOUND, LOCKING(BLUE)
74 107714 MOUNT,CONTROL ﹠ ENCODER LOOP
75 115720 LABEL,CONNECTOR
76 50008-16-C5D SCREW,CAP-HEX HEAD
77 50008-8-C5D SCREW,CAP-HEX HEAD
78 78002 CLAMP,SERIVCE LOOP BRACKET
79 50003-8-C5D SCREW,CAP-HEX HEAD
80 SEE TABLE 3 BRACKET,CONNECTOR-RIGHT HAND
81 SEE TABLE 3 BRACKET,CONNECTOR-LEFT HAND
82 50206-B NUT,HEX – BRASS
83 DELLETED
84 50910-S WASHER,LOCK
85 87074-8-B WASHER,LOCK – STAR (BRASS)
86 118993 CABLE,70mm2YELLOW W/GREEN TRACER
87 115909 BRACKET,MOUNTING,CABLE TRAY
88 115910 BRACKET,MOUNTING,CABLE TRAY
89 115911 CABLE TRAY
90 50004-10-C5D SCREW,CAP-HEX HEAD
91 50804-R-C WASHER,FLAT-REGULAR
92 50304-C NUT,HEX,JAM
93 94872-4 LUG,COPPER CONNECTOR
94 118866 EARTHING BAR ASSY
95 122718-01-20 CABLE,PIGTAIL ASSY COMP(42 COND)
96 124459-01-20 CABLE,PIGTAIL ASSY COMP(18 COND)
97 86871-32 WASHER,NYLON SEALING
98 86872-32-S LOCKWASHER,INTERNAL STAR
99 78317-32 LOCKNUT
100 83444-07 GLAND,CABLE,ARMORED,32mm
101 83444-03 GLAND,CABLE,ARMORED,20mm
102 110022-1B CONNECTOR,SINGLE PIN,POWER,BLK
103 110022-1W CONNECTOR,SINGLE PIN,POWER,WHT
104 110022-1R CONNECTOR,SINGLE PIN,POWER,RED
105 50004-13-C5D SCREW,CAP-HEX HEAD
106 120114 MOUNTING BRACKET, ENCODER
107 120116 SHAFT ADAPTER
108
109 120113 MOUNT,ENCODER
110 120112 MOUNT,SLED
111 120119-1 PULLEY,TIMING
112 120119-2 PULLEY,TIMING
113 125115 SPRING
114 120462 LABEL,TIMING
115 50903-C WASHER,FLAT NARROW
116 120117 BELT,TIMING
117 50804-N-S WASHER,FLAT NARROW
118 110078-FL2 FERRULE,SAFETY CABLE
119 110078-L18 CABLE,SAFETYФ0.32×18″
120 50104-8-S SCREW,SOCKET HEAD CAP
121 50004-4-C5D SCREW,HEX HEAD CAP
122 50004-5-C5D SCREW,HEX HEAD CAP
123 50103-5-BD SCREW,SOCKET HEAD CAP
124 DELETED
125 129421 BRACKET,ANGLE
126 50006-12-C5D SCREW,HEX HEAD CAP
127 DELETED
128 50008-12-C5D SCREW,HEX HEAD CAP
129 83444-04 GLAND
130 50004-8-C5D SCREW,HEX HEAD CAP
131 51804-C NUT,HEW-SLEF LKG<UNC-28)
132 DELETED
133 56609-25 TERMINAL WIRE RING
134 56531-8-S PLUG,O-RING BOSS
135 50182-1-03 SCREW,CAP-BUTTON HEAD
136 55008-12-C5D SCREW,HEX HEAD CAP
137 56706-8-S TEE,PIPE-INT/INT/EXT
138 DELETED
139 56611-8 ELBOW,45° INT ELECT
140 56612-01 SPICE NUT
141 56609-11 TERMINAL WIRE RING
142 50649-61 SCREW
143 50913-S NUT,SELF LOCKING
144 51803-C NUT
145 50810-R-C WASHER,FLAT
总成号 124973 SERVICE LOOP KIT,TDS-9SA(U.L.)
1 SEE TABLE 1 POWER LOOP ASSY,W/CONNECTORS(3*646 MCM)
2 SEE TABLE 1 COMPOSITE CONTROL LOOP ASSY,W/CONNECTORS
3 SEE TABLE 1 AUX POWER LOOP ASSY,W/CONNECTORS
4 117125 RING ASSEMBLY
5 117121-500 CABLE TIE
总成号 124975 DERRICK LOOP ASSY, POWER(W/CONNETORS)
1 114869-SL-BLK CONNECTOR,POWER,SINGLE SOCKET (646 MCM)
2 114869-SL-WHT CONNECTOR,POWER,SINGLE SOCKET (646 MCM)
3 114869-SL-RED CONNECTOR,POWER,SINGLE SOCKET (646 MCM)
4 114869-PL-BLK CONNECTOR,POWER,SINGLE PIN (646 MCM)
5 114869-PL-WHT CONNECTOR,POWER,SINGLE PIN (646 MCM)
6 114869-PL-RED CONNECTOR,POWER,SINGLE PIN (646 MCM)
7 124358-14 LUG,(444 MCM)
8 DEE TABLE HARNESS,CABLE
9 77992-1080 POTTING COMPOUND
10 84514-96-0 TUBING,HEAT SHRINK,BLK
总成号 124977 CABLE KIT,JUMPER(HOUSE TO DERRICK LOOP)
1 114724-BLK-XXX CABLE ASSY,POWER,W/CONNECTOR,BLK (646 MCM)
2 114724-WHT-XXX CABLE ASSY,POWER,W/CONNECTOR,WHT (646 MCM)
3 114724-RED-XXX CABLE ASSY,POWER,W/CONNECTOR,RED (646 MCM)
4 125093-XXX CABLE ASSY,EARTHING(444 MCM)
5 123985-XXX-B CABLE ASSY,COMPOSITE (42 COND)
6 124458-XXX-B CABLE ASSY,AUX POWER (18 COND)
7 50008-12-S SCREW,HEX 1/2″*1 1/2″
8 50208-S NUT,SELF-LOCKING,1/2″
9 50808-R-S WASHER,FLAT,1/2″
10 78310-1 WASHER,BELLEVILLE,1/2″
总成号(121403) 英文名称
序号 部件号 英文名称
1 110562-1 ACCUMULATOR,HYDRO-PNEUMATIC 4”
2 110563-1 ACCUMULATOR,HYDRO-PNEUMATIC 6”
3 110564-1 ACCUMULATOR,HYDRO-PNEUMATIC 2”
4 111712 PRE-FILL VALVE ASSEMLY
5 121403-DWG PACKAGE,HYDRAULIC,TDS-11SA
6 30111013 FILTER,ASSRY,60 MICRON,GEAR OIL
7 114416 FILTER,HYDRAULIC
8 118408-500 TUBE ASSY,MANIFOLD/BRAKE
9 125096 TUBE ASSY,MANIFOLD/SHOT PIN
10 118405 TUBE ASSY,MANIFOLD/LOAD STEM
11 113974 TUBE ASSY,LUBE MOTOR/MANIFOLD
12 119028 TUBE ASSY,HEAT EXCHANGER/FILTER
13 115421 TUBE ASSY,MANIFOLD/LOAD STEM
14 115422 TUBE ASSY,MANIFOLD/LOAD STEM
15 115423 TUBE ASSY,MANIFOLD/LOAD STEM
16 118410 TUBE ASSY,ACCUMULATOR/LOAD STEM
17 117570 TUBE ASSY,MANIFOLD/LOAD STEM
18 115425 TUBE ASSY,MANIFOLD/LOAD STEM
19 113892-500 TUBE ASSY,CASE DRAIN/RESERVIOR
20 116690 TUBE ASSY,C’BAL ACCUM/MANIFOLD
21 113984 TUBE ASSY,PRE-FILL/BULKHEAD
22 113985 TUBE ASSY,RESERVIOR/PRE-FILL MANIFOLD
23 119029 TUBE ASSY,OIL FILTER/PRE-FILL VALVE
24 121511-500 TUBE ASSY,OIL FILTER/MANIFOLD
25 113988 TUBE ASSY,PRESSURE SWITCH/AIR DUCT
26 117091-500 TUBE ASSY,RESERVIOR/VANE PUMP
27 125104 TUBE ASSY,LUBE PUMP MANIFOLD/FILTER
28 125102 TUBE ASSY,MANIFOLD/SHOT PIN
29 125101 TUBE ASSY,MANIFOLD/SHOT PIN
30 125099 TUBE ASSY,MANIFOLD/SHOT PIN
31 125426 TUBE ASSY,MANIFOLD/LOAD STEM
32 125095 TUBE ASSY,MANIFOLD/SHOT PIN
33 114083 TUBE ASSY,MANIFOLD/CASE DRAIN
34 112151 TUBE ASSY,FILTER/QD
35 114086-500 TUBE ASSY,PISTON PUMP/RESERVOIR
36 114085-500 TUBE ASSY,PRE-FILL BULKHD/MANIFOLD
37 118409-500 TUBE ASSY,LUBE/HEAT EXCHANGER
38 114090-500 TUBE ASSY,ACCUMULATOR/C’BAL BULKHEAD
39 56541-12 KIT,FLANGE
40 56541-16 KIT,FLANGE
41 56529-6-6-S CONNECTOR,O-RING BOSS/37′
42 56519-4-4-S ELBOW,O-RING BOSS/37′
43 56529-8-8-S CONNECTOR,O-RING BOSS/37′
44 125103 TUBE ASSY,LUBE PUMP/FILTER
45 121724 TUBE ASSY,PUMP PRESSURE/MANIFOLD
46 56529-16-16S CONNECTOR,O-RING BOSS/37′
47 115918 ADAPTER,PUMP INLET/DRAIN
48 56522-6-6-S ELBOW,BULKHEAD 37’/37′
49 56513-12-S TEE,BULKHEAD UNION 37′
50 121726 TUBE ASSY,PUMP DRAIN/MANIFOLD
51 55913-12-12 VALVED NIPPLE,QD/EXT PIPE
52 55915-12 CAP,DUST-PLASTIC(QD)
53 56161-12-S TEE,INT PIPE
54 124191 HOSE ASSYMPUMP PRESSURE/MANIFOLD
55 56551-16-12S CONNECTOR,O-RING BOSS/INT PIPE
56 125100 TUBE ASSY,LINK ADAPTER LIFT
57 56556-12-6-S REDUCER,O-RING BOSS
58 TBD TUBE ASSY,ACCUMULATOR/MANIFOLD(3/8″)
59 56519-8-8-S ELBOW,O-RING BOSS/37′
60 56519-6-6-S ELBOW,O-RING BOSS/37′
61 121512 TUBE ASSY,QD/MANIFOLD(3/4″)
62 TBD TUBE ASSY,IBOP PRESS SW/MANIFOLD(1/4″)
63 56555-4-4-S TEE,37’/37’/O-RING BOSS
64 56506-16-16S ELBOW,90′ EXT PIPE/37′
65 56506-4-4-S ELBOW,90′ EXT PIPE/37′
66 56501-4-4-S CONNECTOR,EXT PIPE/37′
67 56706-12-S TEE,PIPE-INT/INT/EXT
68 56519-8-6-S ELBOW,O-RING BOSS/37′
69 50006-28-C5D SCREW,CAP-HEX HEAD
70 50006-06-C5D SCREW,CAP-HEX HEAD
71 56160-12-12-S TEE,37’/37’/INT PIPE
72 TBD BRACKET,FILTER
73 50906-C WASHER,LOCK-REGULAR
74 56524-8-8-S CONNECTOR,EXT PIPE/37′
75 56700-24-16S REDUCER,PIPE-EXT/INT
76 56517-16-6-s REDUCER,INT 37’/37′
77 56530-16-16S TEE,37’/37’/O-RING BOSS
78 56501-24-16S CONNECTOR,EXT PIPE/37′
79 108216-12 BALL VALVE
80 53002-12-S TEE,PIPE,EXT/INT/INT
81 56162-4-4-S PLUG,PIPE SQUARE HEAD
82 56524-4-4-S ELBOW,90′ EXT PIPE/37′ LONG
83 94269-2 CLAMP,SINGLE 1/4″ TUBE(NOT SHOWN)
84 94270-4 CLAMP,DBL 3/8″TUBE(NOT SHOWN)
85 94270-6 CLAMP,DBL 1/2″TUBE(NOT SHOWN)
86 940315-20 CONNECTOR,STUFF #TCM20
87 56710-12-8-S REDUCER PIPE ENT/EXT
88 56512-12-8-S EKBIW EX-LONG 90’EXT PIPE/37′
89 56501-12-12S CONNECTOR EXT PIPE/37′
90 56502-16-16S EKBIW 45′ EXT PIPE/37′
91 55008-12-C5D SCREW CAP-HEX HEAD(UNF-2A)
92 53002-2-C PLUG,PIPE SQUARE HEAD
93 56606-8 ELBOW,E/P 1/2 NPT
总成号(121403) 英文名称
序号 部件号 英文名称
1 110562-1 ACCUMULATOR,HYDRO-PNEUMATIC 4”
2 110563-1 ACCUMULATOR,HYDRO-PNEUMATIC 6”
3 110564-1 ACCUMULATOR,HYDRO-PNEUMATIC 2”
4 111712 PRE-FILL VALVE ASSEMLY
5 121403-DWG PACKAGE,HYDRAULIC,TDS-11SA
6 30111013 FILTER,ASSRY,60 MICRON,GEAR OIL
7 114416 FILTER,HYDRAULIC
8 RELOCATED SEE NOTE 6
9 RELOCATED SEE NOTE 6
10 RELOCATED SEE NOTE 6
11 RELOCATED SEE NOTE 6
12 RELOCATED SEE NOTE 6
13 RELOCATED SEE NOTE 6
14 RELOCATED SEE NOTE 6
15 RELOCATED SEE NOTE 6
16 RELOCATED SEE NOTE 6
17 RELOCATED SEE NOTE 6
18 RELOCATED SEE NOTE 6
19 RELOCATED SEE NOTE 6
20 RELOCATED SEE NOTE 6
21 RELOCATED SEE NOTE 6
22 RELOCATED SEE NOTE 6
23 RELOCATED SEE NOTE 6
24 RELOCATED SEE NOTE 6
25 RELOCATED SEE NOTE 6
26 RELOCATED SEE NOTE 6
27 RELOCATED SEE NOTE 6
28 RELOCATED SEE NOTE 6
29 RELOCATED SEE NOTE 6
30 RELOCATED SEE NOTE 6
31 RELOCATED SEE NOTE 6
32 RELOCATED SEE NOTE 6
33 114083 TUBE ASSY,MANIFOLD/CASE DRAIN
34 RELOCATED SEE NOTE 6
35 RELOCATED SEE NOTE 6
36 RELOCATED SEE NOTE 6
37 59024P080032 HOSE ASSY,PUMP/MANIFOLD
38 RELOCATED SEE NOTE 6
39 59046P08X036 HOSE ASSY,BRAKE UNION
40 RELOCATED SEE NOTE 6
41 56541-16 KIT,FLANGE
42 56541-12 KIT,FLANGE
43 56556-16-8-S REDUCER,O-RING,BOSS
44 30171993 KIT,TUBE ASSY,TDS-11SA
45 56519-4-4-S ELBOW,O-RING BOSS/37′
46 30171993 KIT,TUBE ASSY,TDS-11SA
47 56529-6-6-S CONNECTOR,O-RING BOSS/37′
48 56529-8-8-S CONNECTOR,O-RING BOSS/37′
49
50 RELOCATED SEE NOTE 6
51 DELETED
52 56529-16-16S CONNECTOR,O-RING BOSS/37′
53
54 30115918 ADAPTER,PUMP INLET/DRAIN
55 56522-6-6-S ELBOW,BULKHEAD 37’/37′
56 56513-12-S TEE,BULKHEAD UNION 37′
57
58 121726 TUBE ASSY,PUMP DRAIN/MANIFOLD
59 55913-12-12 VALVED NIPPLE,QD/EXT PIPE
60 55915-12 CAP,DUST-PLASTIC (QD)
61 56161-12-S TEE,INT PIPE
62 301241921 HOSE ASSY,PUMP PRESSURE/MANIFOLD
63 56556-16-12S REDUCER
64 RELOCATED SEE NOTE 6
65 56556-12-6-S REDUCER,O-RING BOSS
66 RELOCATED SEE NOTE 6
67 56519-8-8-S ELBOW,O-RING BOSS/37′
68 56519-6-6-S ELBOW,O-RING BOSS/37′
69 RELOCATED SEE NOTE 6
70 RELOCATED SEE NOTE 6
71 56555-4-4-S TEE,37’/37’/O-RING BOSS
72 56506-16-16S ELBOW,90′ EXT PIPE/37′
73 56506-4-4-S ELBOW,90′ EXT PIPE/37′
74 56501-4-4-S CONNECTOR,EXT PIPE/37′
75 56706-12-S TEE,PIPE-INT/INT/EXT
76 56519-8-6-S ELBOW,O-RING BOSS/37′
77 50006-06-C5D SCREW,CAP-HEX HEAD
78 50006-28-C5D SCREW,CAP-HEX HEAD
79 56160-12-12S TEE,37’/37’/INT PIPE
80 50006-12-C5D SCREW,CAP-HEX HEAD
81 129375 BRACKET,FILTER
82 50906-C WASHER,LOCK-REGULAR
83 56524-8-8-S CONNECTOR,EXT PIPE/37′
84 56700-24-16S REDUCER,PIPE-EXT/INT
85
86 56516-12-6-S REDUCER,INT 37’/37′
87
88 56530-12-12S TEE,37’/37’/O-RING BOSS
89 56501-24-16S CONNECTOR,EXT PIPE 37′
90 108216-12 BALL VALVE
91 53002-12-S PLUG PIPE SQUARE HEAD
92 56162-4-4-S TEE,PIPE,EXT/INT/INT
93 56524-4-4-S ELBOW,90′ EXT PIPE/37′ LONG(NOT SHOWN)
94 94269-2 CLAMP,SINGLE 1/4”TUBE (NOT SHOWN)
95 94270-4 CLAMP,DBL 3/8” TUBE (NOT SHOWN)
96 94270-6 CLAMP,DBL 1/2” TUBE (NOT SHOWN)
97 940315-20 CONNECTOR,STAUFF #TCM20
98 56700-12-8-S REDUCER PIPE ENT/EXT
99 Z6001 LOCKWIRE .051
100 56501-12–12S CONNECTOR EXT PIPE/37′
101 56502-16-16S ELBOW 45′ EXT PIPE/37′
102 55008-12-C5D SCREW,CAP-HEX HEAD (UNF-2A)
103 53002-2-C PLUG,PIPE-SQUARE HEAD
104 56606-8 ELBOW,E/P 1/2” NPT
总成号 30154688 KIT,GUIDE BEAM
序号 部件号 英文名称
1 30154381 GUIDE BEAM,BOTTOM INTERMEDIATE SECTION(24 ft）
2 124517-502 GUIDE BEAM,INTERMEDIATE SECTION(24 ft)
3 124517-503 GUIDE BEAM,INTERMEDIATE SECTION(6 ft)
4 124517-501 GUIDE BEAM,INTERMEDIATE SECTION(12 ft)
5 DELETED
6 117782 PIN,JOINT
7 117783 PIN,RETAINER
8 117496-1 PIN,LYNCH
9 30154900-BSC LINK,HANG OFF
10 30154900-500 LINK,HANG OFF
11 30154900-501 LINK,HANG OFF
12 30154900-502 LINK,HANG OFF
13 30154900-503 LINK,HANG OFF
14 DELETED
15 70851 SLING,ROPE,WIRE,25 TON
16 30170000 ASSY,BEAM HOIST
111712PRE-FILL VALVE ASSEMBLY
1 111707-2 VALVE BODY
2 111708 COVER 25mm MODIFIED
3 111709 PLUG,SAE J514-12 SPECIAL
4 111710 GUIDE ROD
5 111711 GUEDE DISC
6 112825 valve,modified-logic cartridge insert
7 53500-68 RETAINING RING INTERNAL
8 53600-40 RETAINING RING,EXTERNAL
9 105643-12 O-RING,3-912
10 109498-800D LEE JET,8000LOHM
11 92654 CHECK VALVE, .187 DIA
12 94536-175N CHECK VALVE,T-13,75PSID
13 93019-19 OFIFICE PLUG, .25-28×.075DIA
14 93024-4SAE SAE-4 TEST FITTING
15 50108-14-BD SOCKET CAP SCREW .50-13×1.75
16 87196-2-S SAE J514-2 HEX SOCKET PLUG
17 87196-4-S SAE J514-4 HEX SOCKET PLUG
18 56519-16-12S SAE-16 ELBOW,O-RING BOSS/37′
19 56519-6-6-S SAE-6 ELBOW,O-RING BOSS/37′
20 56519-12-12S SAE-12 ELBOW,O-RING BOSS/37′
21 53200-242 LOCKTITE,BLULOCK
22 56531-12-S PLUG,O-RING BOSS
23 56529-12-12S CONN.,O-RING BOSS/37′
116199
序号 SIEMENS P/N 中文名称
1 6SE7038-6GK84-1GF0 吸收电路板
2 6SY7000-0AC37 (-2) IGBT 转换模块
3 6SE7038-6GK84-1GG0 逆变器吸收板
4 6SE7036-5GK84-1JC0 逆变器驱动板
5 6SE7038-6GL84-1BG2 逆变器接口板
6 6SE7038-6GK84-1BH0 放大板
7 6SE7038-6GL84-1JB0 分压板
8 6SE7090-0XX84-2FA0 参数优化板
9 6SY7000-0AC30 电容
10 6SY7000-0AC38 电容
11 6SY7000-0AD05 风扇总成
12 6SY7000-0AC40 风扇
13 6SY7000-0AC42 熔断器
14 3NE3336 熔断器
15 6SE7038-6GL84-1JA1 电源模块
16 6SY7000-0AA76 电阻
17 6SY7000-0AB18 电阻
18 6SY7000-0AC33 电阻
19 6SY7000-0AC13 接头
20 6SE7090-0XX84-0AB0 控制板
21 6SY7000-0AA26 熔断器式断路器
22 6SY7000-0AD88 直流母排电容
23 6SY7000-0AC35 风扇电容
24 6SE7038-6UK60 大逆变器
25 6SE7090-0XX85-1DA0 整流器控制板
26 6SE7041-8GK85-0HAD 电源及控制板
27 6SY7010-7AA02 风扇
28 6SY7010-2AA01 熔短器
29 3NE3338 熔断器
30 6SY7010-2AA23 熔断器
31 6SY7010-6AA02 温控开关
32 6SY7010-5AA03 变压器
33 6SY7010-0AB66 带吸收回路的可控硅
34 6SY7010-0AB65 带吸收回路的可控硅
35 6SY7041-0FH85-0AA0 整流单元
36 6SE7090-0XX84-3DB0 DTI板
37 6SE7090-0XX84-4HA0 接口
38 6SE7090-0XX84-2FK0 OPIS面板
39 6SE7090-0XX84-0FF0 通讯板
40 R64-01-876 控制变压器
41 U01MN6 低压脱扣器
42 R64–03-400 电抗器
43 RL-75–002 刹车模块
44 R71-00-248 制动单元
45 DB575-200-33R-S 刹车电阻
46 85H-02-700 开关
47 R32-02-009 熔断器
48 R32-02-011 熔断器
49 R32-02-014 熔断器
50 NONE 风扇支架
51 6EP1336-1SH01 电源
52 接触器
53 过载保护开关
54 接触器
55 过载保护开关
56 R61-01-120 温控开关
57 3NE4120 熔断器
58 6SE7023-0FD61/6SE7023-0UD61 变频器
59 AJT35 熔断器
60 R25-01-167 熔丝支架
61 R31-01-219 顶罩
62 R31-01-220 底罩
63 SKR141F1S 二极管
