100058419 Retainer, Stop and Spring, HT400, No. 3 Suction Valve, Mach. Cast.
100002972 Boot, Suction and Stop, HT-400™, No. 3, 4 and 5 Frac
100002841 Spring, Lock, Suction Stop, No. 3, HT400
100002079 Pin, Cotter, 1/8 x 1 1/2 Inch, HT-400™
100002868 Liner, Two Piece Bushing, Valve Guide, HT400, No.4 Frac, Brass
100002867 Insert, Two Piece Bushing, Valve Guide, Special, HT-400™, No 4 Frac
100002837 Spring, Valve, HT400, No. 3, 3.38 and 4 Inch, 36 lb/in
100002824 Valve, HT400, 3.38, 4.0 In, Frac
101333083 Insert, Valve, HT400, Frac, Acid /Frac (Yellow)
100002825 Seat Valve, HT400, No. 3 Frac, Tapered
100000968 O-ring, 90 Duro, 4 x 3 3/4 x 1/8, 568-240
100002838 Retainer, Guide Bushing, HT400, 3.38, 4.0 Inch, Tapered Seat Bore
4 inch Discharge Assembly100007820 Retainer, Cover, HT-400™, 4.0 in.
100002938 Cover, Discharge, Double Guided Valve, HT-400™, 4.0 and 4.5 in.
100002878 Gasket, Discharge Valve & Cylinder Head Cover, No. 4, HT-400™
100002877 Ring, Spacer, Discharge Valve & Cylinder Head Cover, No.4, HT-400™
4.0 inch Plunger Assembly100011711 Retainer, Protective Cylinder Head Cover, 4.0 in
100002902 Cover, Protective Cylinder Head, 4.0 in(Crush Cap)
100002830 Gasket, 3 Discharge Valve & Cylinder Head Cover, 3 3/8 in
100002829 Ring, Spacer, #3 Discharge Valve & Cylinder Head Cover, 3 3/8
100002911 Nose, Plunger, HT-400™, 4.0 in., Ty Cert
100002884 Seal, Plunger Nose Assembly, HT-400™, 4.0
100002883 Plunger, 4.0 In., Hard Surface, L-Spacer, HT-400™
100002827 Tie Rod, Plunger, HT-400™, 3.38, 4.0, 4.5 in
100011706 Adapter, Pushrod, HT-400™, 4.0 in, Two Piece Nose
4.0 inch Packing Assembly (CDI Type)101377657 Seal, Packing Lube, 4.000, WS-Seal, CDI
100002016 O-Ring, 90 Duro, 5 x 4 3/4 X 1/8 568-248
101377656 Carrier, Seal, 4.000, CDI
101377652 Adapter, Female, 4.000, PEEK, CDI
101377641 Packing, 4.000, CDI, WSP1, PTFE
101377640 Header Ring, 4.000, HNBR, CDI
101377638 Spacer, 4.000, Fluid End, CDI
4.0 inch Packing Assembly (Standard Acid Service Type)100058388 Seal, Packing Lube, Z20, 4 x 4 1/2 x 9/16 Zurcon UCUP, Double Lip FE
100000974 O-Ring, 90 Duro, 5 x 4 3/4 X 1/8 568-248
101389213 Carrier, Seal, 4.0, HT-400™, 2004
101389224 Ring, Backup, Packing, HT-400™ 4.0 in, 2004
100002899 Packing Set, 4 x 5 x 0.50 Stock HT, 3 rings, Hard, Acid Service
100002897 Header Ring, 4 x 5 Packing, Polyurethane, HT-400™ FE
100002896 Adapter, Header Ring, 4 x 5, HT-400™, FE
100058432 Retainer, Stop and Spring, HT400, No. 4 Suction Valve, Mach. Cast.
100007270 Spring, Lock, Suction Stop, No. 4, HT400
100002936 Spring, Valve, HT400, No. 4, 4.5 Inch, 25 lb/in
100002875 Valve, HT400, 4.5 inch, Frac
101333104 Insert, Valve, HT400, No. 4 Frac, Urethane, Acid/Frac Service (Yellow)
100002874 Seat Valve, HT400, No. 4 Frac, Tapered
100000970 O-ring, 90 Duro, 4 1/2 x 4 1/4 x 1/8, 568-244
100002955 Retainer, Guide Bushing, HT400, No. 4, Tapered Seat Bore
4.5 inch Discharge Assembly
4.5 inch Plunger Assembly100007823 Retainer, Protective Cylinder Head Cover, 4.5 in
100002952 Cover, Protective Cylinder Head, 4.5 in(Crush Cap)
100002941 Nose, Plunger, HT-400™, 4.5, 5.0, 6.0 in.
100002940 Seal, Plunger Nose Assembly, HT-400™, 4.5
100002937 Plunger, 4.5 In., Hard Surface, L-Spacer, HT-400™
4.5 inch Packing Assembly (CDI Type)101377665 Seal, Packing Lube, 4.50, WS-Seal, CDI
100002019 O-Ring, 90 Duro, 5 1/2 x 5 1/4 x 1/8 568-252
101377664 Carrier, Seal, 4.50, CDI
101377663 Adapter, Female, 4.500, PEEK, CDI
101377661 Packing, 4.50, CDI WSP1, PTFE
101377660 Header Ring, 4.50, HNBR, CDI
101377659 Spacer, 4.50 in., Fluid End, CDI
4.5 inch Packing Assembly (Standard Acid Service Type)101252286 Seal, Packing Lube, Z20, 4 1/2 x 5 x 9/16 Zurcon UCUP, Double Lip FE
100000977 O-Ring, 90 Duro, 5 1/2 x 5 1/4 X 1/8 568-252
101389214 Carrier, Seal, 4.5, HT-400™, 2004
101389225 Ring, Backup, Packing, HT-400™ 4.5 in, 2004
100002951 Packing Set, 4 1/2x 5 1/2 x 0.50 Stock HT, 3 rings, Hard, Acid Service
100002949 Header Ring, 4 1/2 x 5 1/2 Packing, Polyurethane, HT-400™ FE
100002948 Adapter, Header Ring, 4 1/2 x 5 1/2, HT-400™, FE
100002833 Retainer, Push Rod, HT-400™, Two Piece Nose, LSpacer
100000959 O-Ring, 90 Duro, 1 7/8 x 1 5/8 x 1/8, 568-223
100002832 Push Rod, Two Piece, L-Spacer, HT-400™
100002971 Tie Rod, Push Rod, L-Spacer, HT-400™
100013017 Screw, Hex Cap, 3/8-16 NC x 1, PL, Spec 70.43917
100013059 Washer, Lock, 3/8, Steel, PL, Spec
100002804 Retainer, Push Rod Seal Housing, L-2 Spacer, HT-400™ Pump
100001903 O-Ring, 70 Duro, 5 11/16 x 5 1/2 x 3/32 568-161
100002805 Housing, Push Rod Seal, Floating, L-2 Spacer, HT-400™
100002806 Seal, Push Rod, L-Spacer, HT-400™
